Honeywell F6001

What is the Honeywell F6001?

Honeywell F6001 Control Card gathers and deploys the signals and logic associations relating to fire extinguishing control. Using the inputs and outputs managed by the other cards of the H-S81-HS panel, it enables system compliance with the EN 12094-1 standard. It does not have physical I/O, but uses inputs and commands managed by other cards of the H-S81-HS system.

It performs the functions of an ECD. It allows building fire extinguishing systems certified SIL2 and SIL3 (IEC 61508). It manages 4 virtual inputs (V-IN) and 10 virtual outputs (V-OUT). It can be hot-swapped. It makes the S81 System compliant with EN 12094-1 Features & Benefits:

0-60 second extinguishing control delay is configurable at operator level 3

Can be hot-swapped

Communication management by FPGA

Internal logic management by micro-controller

SMD technology multilayer circuit

Front plug-in on 19'' rack, with locking screwsCertifications:

EN 12094-1

Certified by an accredited body to the European C.P.D. Construction Product Directive (Cert. n° 051-CPD-0139/0138/0137)

IEC 61508

Honeywell Honeywell Industrial Fire F6001 — Honeywell F6001 Control Card gathers and deploys the signals and logic associations relating to fire extinguishing control. It does not have physical I/O, but uses inputs and commands managed by other cards of the H-S81-HS system. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.
