Honeywell BDA-25V

Back-Up Digital Amplifier

MPN: BDA-25V
Category: Honeywell Fire Alarm Panels & Modules

Price and lead time confirmed within 1 business day

Discontinued by Honeywell — we can still source the original BDA-25V (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Honeywell parts? We buy surplus →

What is the Honeywell BDA-25V?

The DAA2 series amplifiers are multi-featured digital audio amplifiers capable of playing up to two of 8 channels of digital audio; can play up to two different messages simultaneously with the optional BDA amplifier. Each DAA2 amplifier includes a firefighter/emergency telephone riser circuit and remote paging microphone circuit. The backup digital amplifiers provide an economical means of backing up DAA2 and DAX amplifiers in a one-to-one primary/backup configuration. A BDA can also provide a second audio channel for a DAA2 when programmed as a primary amplifier in VeriFire Tools. A BDA is not addressable it is considered a part of the digital amplifier to which it is attached. The BDA may be programmed and wired for backup or for providing a second audio channel. Features & Benefits:

The volume of the BDA’s group can be changed using VeriFire Tools, NCA-2, ONYXWORKS, or direct-connect NFS2-3030

With BDA-25/70 card used as backup, 50 watts audio output from the DAX, or 50 watts audio output

from the BDA

Provides backup for DAA2 and DAX

Provides second audio channel for DAA2

supports one-to-one backup (all DAA2 models)

supports two-channel operation (all DAA2 models)

Supports one-to-many amplifier backup applications using the same model DAA2Certifications:

UL Listed: S635

ULC Listed: S635

CSFM: 7165-0028:0234 (NFS2-640/NFS-320), 7165-0028:0224 (NFS2-3030)

Fire Dept. of New York: COA#6121 (NFS2-640/NFS-320), COA#6114 (NFS2-3030)

FM Approved

Seismic

Honeywell NOTIFIER BDA-25V — BDA Digital amplifiers can be used to provide one-to-one amplifier backup. Also BDA supports two-channel operation and it can be use to increased output wattage to 100W. Discontinued by Honeywell — no longer in the current range. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Discontinued by Honeywell
Brand line	NOTIFIER

Others

Brand

NOTIFIER

Ordering codes

Part numbers on this product page

BDA-25V, BDA-70V
