Honeywell 808630.10

Esserbus Transponder RTZ

MPN: 808630.10
Category: Honeywell Building Management Systems (BMS)

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Honeywell parts? We buy surplus →

What is the Honeywell 808630.10?

Esserbus transponder is a refurbishment zone transponder for the fire alarm system 8000, IQ8Control and FlexES Control FACPs. Individual automatic fire detectors and manual call points (conventional technology) from other manufacturers can be connected to the 4 zone inputs of transponder. The voltage of all 4 zones can be configured to 24 V via the internal DC/DC module. An additional reset module is not required to operate third-party detectors. It has two relay outputs for general control purposes. Features & Benefits:

For connection of 3rd party detectors

Only one loop address is needed per transponder

Max. 100 transponders per FACP

Max. 31 transponders per loop

Output current max. 125 mA per detector zone

Variable reset delay of the detector zone (0 to 15 seconds)Certifications:

VdS

Honeywell ESSER 808630.10 — Esserbus transponder is a refurbishment zone transponder for the fire alarm system 8000, IQ8Control and FlexES Control FACPs. Transponder generates 24V DC detector zone voltage inside the module. PartnerPLC sources new, surplus and discontinued Honeywell parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Active
Brand line	ESSER

Others

Brand

ESSER
