Danfoss 858AN00097A

KBFDG4V-3-2C28S-Z-M1-PC7-H6-12, KBFDG4V32C28SZM1PC7H612

MPN: 858AN00097A
Category: Industrial valves

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss 858AN00097A?

Danfoss KBFDG4V-3-2C28S-Z-M1-PC7-H6-12, KBFDG4V32C28SZM1PC7H612, manufacturer part number 858AN00097A. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A Port flow LPM	28.00
A Port flow USGPM	7.40
Actuation Type	Solenoid controlled
B Port flow LPM	28.00
B Port flow USGPM	7.40
Brand	Vickers by Danfoss
Build orientation	Solenoid 'B' at port 'A' end of valve and solenoid 'A' at port 'B' end of valve
Build type	Spring centered
Coil voltage	24 Volt DC
Command input	+/-10V Command +/-10V feedback
Communication protocol	None
Current	3 amp
Design Series	12 Series
Electrical Connection	Electrical (PC7) 7 pin connector without plug
Feedback sensor	Yes
Fluid Cleanliness	17/15/12 micron
Fluid compatibility	Antiwear hydraulic oils and non alkyl-based Phosphate Esters
Interface	ISO4401-03/NFPA D03/CETOP 3/NG06
Manual override	None
Maximum pressure BAR	350
Maximum pressure PSI	5000
Metering	Meter out
Model Code 1	KBFDG4V32C28SZM1PC7H612
On board electronics	Yes
Performance	High performance
Pressure drop rated flow BAR	5
Pressure drop rated flow PSI	72
ProFX compatible	No
Reducer module	No
Reverse flow check	No
Seal type	Viton
Special features	None
Spool Type	ISO4401-10/NFPA D10/CETOP 10/NG32
Stage	Single stage
Symmetric flow	Yes
Tank port rating BAR	210
Tank port rating PSI	3000
Valve Mount Type	Subplate
Valve type	Proportional directional
Working temp max C	70
Working temp max F	158
Working temp min C	-20
Working temp min F	-4
