Danfoss 84013167

MPN: 84013167
Category: Standard hydraulic power units

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Danfoss 84013167?

Danfoss , manufacturer part number 84013167. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Accessory ready	Not required
Accumulator with manual dump	Not required
Air bleed	Not required
Communication interface	Not required
Containment tray	Not required
Cooling	Not required
Design	Low pressure(UP TO 3000PSI)sae
Directional valve coil voltage	120VAC 60HZ / 110VAC 50HZ
Directional valve lights	Not required
Drive size	Not required
Filler/breather	Standard filler/breather
Filter	25 GPM, 10um, spin-on return
Future expansions	TBD - future expansion
Low level/temp switch	Not required
Manifold w/rel or inline rel	1-Station manifold
Manifold/valve size	D03
Motor	3/4HP 230/460/60+190/380/50
Motor type	Gen. purpose VFD ready-700/300
Motor variable frequency drive	Not required
Paint	Default-danfoss grey ral-7024
Pressure gauge/sensor	0-3000 PSI
Product Series	System pak
Pump	3.3 CC(.20 CID) / Rev vane
Pump controls	Standard control
Reservoir	3 Gallon/11 Liter
Station1 dir or prop valve	3P/4W spring center-tandem
Station1 position1 stack valve	Not Required
Station1 position2 stack valve	Not Required
Station1 position3 stack valve	Not Required
Station2 dir or prop valve	Not Required
Station2 position1 stack valve	Not Required
Station2 position2 stack valve	Not Required
Station2 position3 stack valve	Not required
Station3 dir or prop valve	Not required
Station3 position1 stack valve	Not Required
Station3 position2 stack valve	Not required
Station3 position3 stack valve	Not required
Station4 dir or prop valve	Not required
Station4 position1 stack valve	Not required
Station4 position2 stack valve	Not required
Station4 position3 stack valve	Not required
