Danfoss 12001200

PVX-180-R-LR-0000-088-10Hyd Piston Pump, PVX-180-R-LR-0000-088-10000A3F1000100H000008810

MPN: 12001200
Category: Hydrokraft heavy-duty open-circuit piston pumps

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 12001200?

Danfoss PVX-180-R-LR-0000-088-10Hyd Piston Pump, PVX-180-R-LR-0000-088-10000A3F1000100H000008810, manufacturer part number 12001200. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Pump	Open loop pump
Displacement type	Variable
Series	X-series
Configuration	Single unit
Displacement	180 ccm/rev
Basic Standard	Metric
Mounting Flange	ISO3019/2 160A2SW
Rotation direction	Clockwise
Max displacement set	Max Disp Adj Screw
Thru drive options	SAE C
Main port	SAE Port Metric Bolts
Main port orientation	Radial (side ports)
Main drive shaft end	ISO Straight key
Drive shaft seal config	Single shaft seal
Seal material	FKM
Yoke position indicator	No position indicator
Surface coating	Primer jet black RAL 9005
Control type	Power control
Disp adj options	Not applicable
Electronic amplifier	No amplifier card / n/a
Yoke displacement zone	Single side center A
Additional functions	Load Sensing & Pressure Limiter
Pressure control options	Remote port
Power control	kW at 1500 ppm
Pilot oil filter	None
V-valve_pilot oil sup	Solenoid valve
Position monitoring	Not applicable
Electric motor type	Not applicable
Control voltage	24 V DC
Customer adjustment	None
Special feature	per Data Specified in SF Table No
Design number	per data spec. in D. table 10
Brand	Danfoss
IPM FRAME SIZE	PVX-180cc 10 design Pump
Model Code 1	PVX-180-R-LR-0000-088-10
Model Code 2	000A3F1000100H000008810
Sub brand	Hydrokraft
