HOSE NIPPLE ASSY,GR/20,DGLOBE/20,CS,90D
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Braided hose and fittings |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 07.031-28-20 be shipped?
07.031-28-20 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 07.031-28-20 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 07.031-28-20 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 07.031-28-20, subject to availability and destination.
Danfoss HOSE NIPPLE ASSY,GR/20,DGLOBE/20,CS,90D, manufacturer part number 07.031-28-20. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| A dimension IN | 4.370 |
| A dimension MM | 111.000 |
| Angle shape | 90 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 1.250 |
| Compatible hose ID MM | 31.800 |
| Construction Style | Reusable |
| Drop dimension IN | 2.810 |
| Drop dimension MM | 71.50 |
| End size 1 | -20 |
| End type 1 | Male JE metric |
| Finish plating | Zinc plating |
| Hex size 1 IN | 1.420 |
| Hex size 1 MM | 36.100 |
| Hex size 2 IN | 1.610 |
| Hex size 2 MM | 41.000 |
| Hose cut off factor IN | 3.050 |
| Hose cut off factor MM | 77.500 |
| Hose size | -20 |
| Inside diameter IN | 0.870 |
| Inside diameter MM | 22.100 |
| Product height in | 3.720 |
| Product height mm | 94.448 |
| Product length in | 5.180 |
| Product length mm | 131.572 |
| Product material | Carbon steel |
| Product width in | 1.810 |
| Product width mm | 45.974 mm |
| Series | Teflon Reusable |
| Thread sealant | No |
| Thread size 1 | M36x2 |
| Working temperature max C | 121 |
| Working temperature max F | 250 |
| Working temperature min C | -54 |
| Working temperature min F | -65 |
