Home / Bosch Rexroth / ML3 self-cooled linear motors / Bosch Rexroth R911391905

Bosch Rexroth R911391905

PRIMARY PART LINEAR MOTOR ML3P11-HNBCN-BANNN-NN

MPN: R911391905
Category: ML3 self-cooled linear motors

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Bosch Rexroth R911391905?

The Rexroth servo motors product range combines high dynamics with compact dimensions and best energy efficiency. Rotors with low and medium inertia are available with optimum mass customization. For intelligent solutions in the Industry 4.0 environment, the motors serve as data sources. Special explosion proof versions according to ATEX round out the portfolio.

Specifications

Cooling type	Self-cooling
Maximum standstill continuous current [A]	21.0
Maximum current [A]	19.4
Width [mm]	434
Depth [mm]	125.5
Total height [mm]	45.0
International protection code	IP40
Maximum standstill current [N]	3600
Maximum force [N]	3500
Maximum speed at Fmax [m/min]	55
Continuous standstill current [N]	1520
electrical connection	2 cables (power/sensor system separately)
Continuous current at dead halt 60 K [A]	6.6
Weight [kg]	10.4
