Bosch Rexroth R911342546
SERVOMOTOR MAD180C-0150-SA-S2-DH0-35-A1
- MPN
- R911342546
- Category
- MAD Force-ventilated
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the Bosch Rexroth R911342546?
The high power density predestines the MAD motor series for applications in machine tools and printing machines as well as in metal forming. Fine-resolution encoder systems in single-turn or multi-turn design as well as outstanding radial runout ensure maximum machining precision. In addition to options such as keyway and holding brake, these motors are also available with special bearings for high-speed applications or for applications with increased radial loads. The motor degree of protection IP65 includes the blower motor and thus enables use even in rough industrial environments. The service-friendly motor design even allows easy fan replacement while the motor is running – particularly interesting in the printing industry.
Specifications
Specifications
| Maximum torque [Nm] | 681.0 |
| Maximum speed [rpm] | 6000.0 |
| Rated speed [min⁻¹] | 1500 |
| Flange size [mm] | 325 |
| Rated power [kW] | 42.4 |
| Cooling type | Axial fan, blowing |
| Motor type | without holding brake |
| Rated torque [Nm] | 270.0 |
| Maximum current [A] | 182.12 |
| Shaft length [mm] | 140 |
| Shaft diameter [mm] | 60 |
| Spigot [mm] | 300 |
| Bolt circle [mm] | 350 |
| Rotor inertia (without brake) value [kg/m²] | 0.458 |
| Encoder design | Optical encoder, single-turn EnDat2.1, with 2048 increments |
| electrical connection | Terminal box, rotatable - right |
| Weight [kg] | 334 |
R911342546: frequently asked questions
When can R911342546 be shipped?
R911342546 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up R911342546 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for R911342546 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for R911342546, subject to availability and destination.
