Bosch Rexroth R911173559

FUNCTIONAL MODULE S20-INC-2

MPN: R911173559
Category: Function Modules

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Bosch Rexroth parts? We buy surplus →

What is the Bosch Rexroth R911173559?

The modular, compact device design of the I/O systems from Rexroth provides you with maximum flexibility for cost-effective implementation of your custom machine concepts. The I/O modules have a robust design and mechanics, Forced ventilated - Axial fan 230Vre easy to handle, have a fast reaction time and are quick to install – both in the control cabinet as well as in the field. Open communication standards allow you to perfectly integrate the I/O modules with maximum availability.

Compact, modular and simple

Space-saving I/O technology for top hat rail mounting

Individually combinable modules

Innovative assembly and installation concept

Specifications

Connection type	Push-in
Connectivity technology	1-wire technique (optional 2-wire, 3-wire)
Number of channels	2
Width [mm]	53.6
Height [mm]	54
Depth [mm]	126.1
International protection code	IP20
Input frequency	Max. 300 kHz
Signal voltage "0" [V]	-3-5
Signal voltage "1" [V]	11-30
Nominal output voltage [V DC]	24
Voltage level of the signals	Differential signal (signal ‒ inverted signal) min. ±0.5 V, max. ±6 V
Logic voltage UBus [V DC]	5
Encoder supply voltage [V DC]	5
Conductor cross-section	AWG: 24 ... 16; Flexible: 0.2-1.5 mm²; rigid: 0.2-1.5 mm²
Encoder signals inputs	Symmetric or asymmetric encoders
Permissible air humidity (storage) [%]	5-95
Permissible air humidity (transport) [%]	5-95
Ambient temperature (storage and transport) [°C]	-40-85
Ambient temperature (during operation) [°C]	-25-60
Air pressure (operation)	70-106 kPa (up to 3,000 m above sea level)
Air pressure (storage / transport)	70-106 kPa (up to 3,000 m above sea level)
Weight [kg]	0.26
