CONNECTING ANGLE 2D2-200-A2
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Connection elements for Small Modules SMS |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can R02680C008 be shipped?
R02680C008 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up R02680C008 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for R02680C008 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for R02680C008, subject to availability and destination.
2D and 3D cantilever systems can be set up by the customer with the angle brackets and connection plates of the Small Modules. The performance data of these multi-axis systems and instructions for the quick and easy selection and setup of the appropriate components are provided in the "Documents" folder.
Specifications
Specifications
| Application | 2D cantilever / 3D cantilever |
| Combination of axes | SMS-080/SMS-050 |
| Size of the basic axis | SMS-080 |
| Size of the attached linear axis | SMS-050 |
| Accessories for Small Modules | Angle bracket |
| Type | 2D2/3D1 |
| Maximum travel range smax x-axis [mm] | 1200.0 |
| Maximum travel range smax y-axis [mm] | 200.0 |
| Payload 2D2 x-20 [kg] | 3.33 |
| Payload 3D1 x-20, y-10, y200, z100 [kg] | 0.38 |
| Weight [kg] | 1.54 |
