Beckhoff IP2020-B518

Fieldbus Box, 8-channel digital output, CANopen, 24 V DC, 2 A, Ø8, integrated T-connector

MPN: IP2020-B518
Category: I/O service products (discontinued)

Price and lead time confirmed within 1 business day

Discontinued by Beckhoff — we can still source the original IP2020-B518 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Beckhoff parts? We buy surplus →

What is the Beckhoff IP2020-B518?

The IP2020-Bxxx digital output connects the binary control signals from the automation unit on to the actuators at the process level. The eight outputs handle load currents of up to 2 A each, although the total current is limited to 4 A. This makes these

Beckhoff IP2020-B518 — Fieldbus Box, 8-channel digital output, CANopen, 24 V DC, 2 A, Ø8, integrated T-connector. Beckhoff service-phase product: no longer in the current range. PartnerPLC sources discontinued and surplus Beckhoff automation parts — request a quote for price, condition and lead time.

Specifications

Technical data

Lifecycle	Service phase (discontinued, no longer in Beckhoff's product range)
Number of outputs	8
Output connections	8 mm, snap type
Load type	ohmic, inductive, lamp load
Nominal output voltage	24 V DC (-15%/+20%)
Max. output current	2 A per channel, individually short-circuit proof, ∑ 4 A
Short-circuit current	max. 4 A
Auxiliary power current	typ. 30 mA per channel
Current consumption from U S (without sensor current)	see documentation
Power supply connection	feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, a-coded
Bit width in the process image	8 outputs
Electrical isolation	channels/control voltage: no, between the channels: no, control voltage/fieldbus: depends on the bus system
Extension modules	–
Digital peripheral signals	according to I/O type
Analog peripheral signals	according to I/O type
Number of PDOs (CANopen)	16 send and 16 receive process data objects
Additional CANopen features	life, node guarding, emergency object, variable mapping, store/restore
Configuration	via KS2000 or the controller (service data objects)
Transmission rate	automatic detection of 10 kbaud up to 1 Mbaud
Bus interface	1 x M12 plug, 5-pin, 1 x M12 socket, 5-pin (tee-connector integrated)
Transmission medium	shielded copper cable, 2 x signal, 1 x CAN ground (recommended)
Power supply	control voltage: 24 V DC (-15%/+20%); load voltage: according to I/O type
Box supply current	45 mA + current consumption of sensors, max. 0.5 A
Operating modes	synchron, cyclic, event driven, polling
Operating temperature	0…55°C
Storage temperature	-25…+85°C
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP65/66/67 (conforms to EN 60529)/variable
Approvals/markings	CE, UL
