Balluff BNS01J4

BNS 819-D03-E12-62-10 – Mechanical multiple position limit switches

MPN: BNS01J4
Category: Mechanical multiple position limit switches

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Balluff parts? We buy surplus →

What is the Balluff BNS01J4?

Balluff BNS01J4 (BNS 819-D03-E12-62-10) — Mechanical multiple position limit switches. Dimension: 120 x 72 x 64 mm; Housing material: Aluminum, Anodized; Number of switching positions: 3x E-Chisel; Version: Snap contact; Operating principle: 1-3. Switch position: Mechanical. PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Active
Type designation	BNS 819-D03-E12-62-10
Product group	Mechanical multiple position limit switches

Key features

Dimension	120 x 72 x 64 mm
Housing material	Aluminum, Anodized
Number of switching positions	3x E-Chisel
Version	Snap contact
Operating principle	1-3. Switch position: Mechanical
Continuous current	1-3. Switch position: 6 A
Rated operating voltage Ue	1-3. Switch position: 250 V AC
Installation	Vertical
Approach direction	longitudinal, parallel to attachment surface
Approach speed	1-3. Switch position: 30 m/min
Switch position spacing	12 mm
Connection type	1-3. Switch position: Screw terminal
Ambient temperature	-5...85 °C
IP rating	IP67
Approval/Conformity	CE UKCA CCC WEEE

Classifications

ECLASS 14.0	27-27-06-02
ETIM 9.0	EC001829
UNSPSC 11	41111900
