Balluff BNS00W6
BNS 813-D03-R12-100-20-02-FC – Mechanical multiple position limit switches with safety switch positions
- MPN
- BNS00W6
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Balluff BNS00W6?
Balluff BNS00W6 (BNS 813-D03-R12-100-20-02-FC) — Mechanical multiple position limit switches with safety switch positions. Dimension: 120 x 80 x 83 mm; Housing material: Aluminum, Anodized; Number of switching positions: 3x Roller; Version: Safety EN 60204-1; Operating principle: 1-3. Switch position: Mechanical. PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.
Specifications
Product
| Lifecycle | Active |
| Type designation | BNS 813-D03-R12-100-20-02-FC |
| Product group | Mechanical multiple position limit switches with safety switch positions |
Key features
| Dimension | 120 x 80 x 83 mm |
| Housing material | Aluminum, Anodized |
| Number of switching positions | 3x Roller |
| Version | Safety EN 60204-1 |
| Operating principle | 1-3. Switch position: Mechanical |
| Continuous current | 1-3. Switch position: 6 A |
| Rated operating voltage Ue | 1-3. Switch position: 250 V AC |
| Installation | Vertical |
| Approach direction | longitudinal, parallel to attachment surface |
| Approach speed | 1-3. Switch position: 60 m/min |
| Switch position spacing | 12 mm |
| Connection type | 1-3. Switch position: Screw terminal |
| Ambient temperature | -5...85 °C |
| IP rating | IP67 |
| Approval/Conformity | CE UKCA CCC WEEE |
Classifications
| ECLASS 14.0 | 27-27-06-02 |
| ETIM 9.0 | EC001829 |
| UNSPSC 11 | 41111900 |
