Balluff BNS00KA

BNS 819-D05-R12-100-10-FD-S90R – Mechanical multiple position limit switches

MPN: BNS00KA
Category: Mechanical multiple position limit switches

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Balluff parts? We buy surplus →

What is the Balluff BNS00KA?

Balluff BNS00KA (BNS 819-D05-R12-100-10-FD-S90R) — Mechanical multiple position limit switches. Dimension: 120 x 105 x 85 mm; Housing material: Aluminium, Anodized; Number of switching positions: 5x Roller; Version: Snap contact; Operating principle: 1-5. Switch position: Mechanical. PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Active
Type designation	BNS 819-D05-R12-100-10-FD-S90R
Product group	Mechanical multiple position limit switches

Key features

Dimension	120 x 105 x 85 mm
Housing material	Aluminium, Anodized
Number of switching positions	5x Roller
Version	Snap contact
Operating principle	1-5. Switch position: Mechanical
Continuous current	1-5. Switch position: 5 A
Rated operating voltage Ue	1-3. Switch position: 6…60 V 4. Switch position: 30 V AC/36 V DC 5. Switch position: 6…60 V
Installation	Vertical
Approach direction	longitudinal, parallel to attachment surface
Approach speed	1-5. Switch position: 60 m/min
Switch position spacing	12 mm
Connection type	1. Switch position: Connector
Ambient temperature	-5...85 °C
IP rating	IP67
Approval/Conformity	CE UKCA CCC WEEE

Classifications

ECLASS 14.0	27-27-06-02
ETIM 9.0	EC001829
UNSPSC 11	41111900
