Balluff BNS00FM

BNS 819-D04-D12-100-10-FD-S80S – Mechanical multiple position limit switches

MPN: BNS00FM
Category: Mechanical multiple position limit switches

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Balluff parts? We buy surplus →

What is the Balluff BNS00FM?

Balluff BNS00FM (BNS 819-D04-D12-100-10-FD-S80S) — Mechanical multiple position limit switches. Dimension: 120 x 90 x 85 mm; Housing material: Aluminum, Anodized; Number of switching positions: 4x Chisel; Version: Snap contact; Operating principle: 1-4. Switch position: Mechanical. PartnerPLC supplies new, surplus and discontinued Balluff parts — request a quote for price, condition and lead time.

Specifications

Product

Lifecycle	Active
Type designation	BNS 819-D04-D12-100-10-FD-S80S
Product group	Mechanical multiple position limit switches

Key features

Dimension	120 x 90 x 85 mm
Housing material	Aluminum, Anodized
Number of switching positions	4x Chisel
Version	Snap contact
Operating principle	1-4. Switch position: Mechanical
Continuous current	1-4. Switch position: 4 A
Rated operating voltage Ue	1-4. Switch position: 6…60 V
Installation	Vertical
Approach direction	longitudinal, parallel to attachment surface
Approach speed	1-4. Switch position: 40 m/min
Switch position spacing	12 mm
Connection type	1. Switch position: Connector
Ambient temperature	-5...85 °C
IP rating	IP67
Approval/Conformity	CE UKCA CCC WEEE

Classifications

ECLASS 14.0	27-27-06-02
ETIM 9.0	EC001829
UNSPSC 11	41111900
