ABB PSTX142-600-70
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Power regeneration with variable speed drives |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 7 kg |
Shipping & availability
When can PSTX142-600-70 be shipped?
PSTX142-600-70 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up PSTX142-600-70 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for PSTX142-600-70 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for PSTX142-600-70, subject to availability and destination.
The softstarter PSTX142-600-70 has a rated maximum operational current of 142 A with an operating voltage span from 208...600 V AC. The rated control voltage is between 100...250 V AC at 50/60 Hz. PSTX features a three-phase control soft start and stop through a voltage or a torque ramp. It has built-in bypass for easy installation and energy saving. A RUN, TOR and Event signal is available from relay outputs in NO (normally open state). The PSTX has functions such as current limit, kickstart, analog output, EOL, motor heating and pump cleaning. PSTX also features features jog, braking, stand-still brake, diagnostics, sequence start and emergency/fire pump mode as standard.To interact with PSTX, it has a detachable full graphic display with IP66 and 4x outdoor rating. There are four ways to communicate with PSTX. It can be done by hardwire inputs Start/Stop/Reset of fault, and by three programmable digital inputs. Another popular option is the built-in Fieldbus communication Modbus RTU and incl optional ANYBUS modules with every major protocol such as for example Profinet, Profibus, Modbus TCP, Ethernet IP and others. Another way to communicate with PSTX is to use an external adaptor and a Fieldbus plug. PSTX is the complete alternative for any motor starting application. It’s suitable for medium to large-sized three-phase motors with nominal currents from 30...1250 A inline connection or 52...2160 A inside delta connection. Typical applications are, for example, pumps, fans, compressors, and conveyors.
Specifications
Ordering
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85371091 |
Popular Downloads
| Data Sheet, Technical Information | 1SFC132012C0201 |
| Instructions and Manuals | 1SFC132428M0201 |
| Instructions and Manuals (Part 2) | 1SFC132081M0201 |
| Instructions and Manuals (Part 3) | 1SFC132060M0201 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| EPLAN Data | 9AAC181166_EPLAN |
| Wiring Diagram | N/A A |
Dimensions
| Product Net Width | 199 mm mm |
| Product Net Height | 377 mm mm |
| Product Net Depth / Length | 283.3 mm mm |
| Product Net Weight | 7 kg kg |
Technical
| Rated Operational Voltage | 208 ... 600 V AC V |
| Rated Control Supply Voltage (Us) | 100 ... 250 V AC V |
| Rated Control Circuit Voltage (Uc) | 24 V DC V |
| Rated Frequency (f) | 50/60 Hz, Main Circuit 50 / 60 Hz Hz |
| Rated Operational Power - In-Line Connection (Pe) | (230 V) 37 kW, (400 V) 75 kW, (500 V) 90 kW V |
| Rated Operational Current - In-Line Connection (Ie) | 142 A A |
| Rated Operational Power - Inside Delta Connection | at 230 V 75 kW, at 400 V 132 kW, at 500 V 160 kW V |
| Rated Operational Current - Inside Delta Connection | 245 A A |
| Service Factor Percentage | 100 % |
| Overload Protection | Built-in electronic overload protection |
| Integrated Electronic Overload | Yes |
| Starting Capacity at Maximum Rated Current Ie | 4xIe for 10s |
| Ramp Time | 1 ... 120 second [unit of time] |
| Initial Voltage During Start | 10 ... 99 % |
| Step Down Voltage Special Ramp | 100 ... 10 % |
| Current Limit Function | 1.5 ... 7.5 xle |
| Switch for Inside Delta Connection | Yes |
| Run Signal Relay | Yes |
| By-pass Signal Relay | Yes |
| Fault Signal Relay | Yes |
| Overload Signal Relay | Yes |
| Analog Outputs | 0…10 V, 0…20 mA, 4…20 mA V |
| Signal Indication Ready to Start/Standby ON (LED) | Green |
| Signal Indication Running R (LED) | Green |
| Signal Indication Protection (LED) | Yellow |
| Signal Indication Fault (LED) | Red |
| Communication | Modbus-RTU; Modbus-TCP; Ethernet-IP; EtherCAT; DeviceNet; CANopen; Profibus; Profinet; BACnet-IP; BACnet-MSTP IP |
| Degree of Protection | acc. to IEC 60529, IEC 60947-1, EN 60529 Main Terminals IP00 |
| Terminal Type | Main Circuit: Bars |
| Connecting Capacity Main Circuit | Hole Diameter 8.5 mm mm |
| Connecting Capacity Control Circuit | Rigid 1 x 2.5 mm² mm |
| Connecting Capacity Supply Circuit | Rigid 1 x 2.5 |
| Tightening Torque | Main Circuit 14 N·m m |
| Product Main Type | PSTX142 |
| Function | Auto phase sequence detection, Automatic restart, Current limit, Current limit ramp, Dual current limit, Dynamic brake, Electricity metering, Electronic overload Time-to-cool, Emergency mode, Event log, Full voltage start, Jog with slow speed, forward and reverse, Keypad password, Kick start, Limp mode with two-phase motor control if one set of thyristors is shorted, Motor heating, Pre-start function, Pump cleaning, Real time clock, Sequence start, Soft start with torque control, Soft start with voltage ramp, Soft stop with torque control, Soft stop with voltage ramp, Stand still brake, Start reverse (external contactors), Thyristor runtime measurement, Torque limit, Voltage sags detection |
| Protection Function | Bypass open protection; Current imbalance protection; Current underload protection; Dual overload (separate overload for start and run); Earth fault protection / ground fault protection; Electronic overload protection, EOL; Extension IO failure protection; Fieldbus failure protection; HMI failure protection; Locked rotor protection; Max number of starts/hour; Over voltage protection; Phase reversal protection; Power factor underload protection; PT-100 connection; PTC connection; Too long current limit protection; Too long start time protection; Under voltage protection; User defined protection; Voltage imbalance protection |
| Warning Details | Current imbalance warning; Current underload warning; Electronic overload Time-to-trip; EOL warning; Faulty fan warning; Locked rotor warning; Motor runtime limit warning; Over voltage warning; Phase loss warning (for standby); Power factor underload warning; Short circuit warning (for Limp mode); THD(U) - Total Harmonic Distortion warning; Thyristor overload warning (SCR); Under voltage warning; Voltage imbalance warning |
Technical UL/CSA
| Horsepower Rating UL/CSA | (200 ... 208 V AC) Three Phase 40 Hp, (220 ... 240 V AC) Three Phase 50 Hp, (440 ... 480 V AC) Three Phase 100 Hp, (550 ... 600 V AC) Three Phase 125 Hp V |
| Maximum Operating Voltage UL/CSA | Main Circuit 600 V V |
| Tightening Torque UL/CSA | Main Circuit 123.9 |
Environmental
| Ambient Air Temperature | Operation -25 ... +60 °C, Storage -40 ... +70 °C |
Material Compliance
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2022-006481 |
| RoHS Declaration | 2CMT2022-006500 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | 26f21088-b8bb-4914-b092-1fc09456661d China |
| Simplified SCIP | 0ab76afe-9586-406c-b1d9-3f72d29c6360 Netherlands, 117db3bc-26f8-486b-9661-9213c47e0dce Germany, 13efe971-0aef-4a3e-b200-9388f7b13699 Sweden, 14290cdf-4981-4228-ac25-fbf6ff6bede1 Poland, 2a18edcd-ab8d-49d6-9e8e-a36742111f1c Belgium, 3833bc73-a767-402d-b8b2-abad0c0099a9 Norway, 3ac3b2ef-d72e-4baa-a85b-7a6308c05cd5 France, 3ce45bbe-7f17-4746-a062-621c143a1593 Belgium, 45148e2f-b3ab-4084-a4ff-2d3992dff4e3 Greece, 483327c0-4c3f-426a-8884-5793dc883e80 Germany, 4895692a-8d27-4479-86bf-173e094805d8 Finland, 693ca665-b359-42b9-8505-0a1d73f17bb1 Croatia, 721706c8-8f98-4edd-93f6-85eb76f49408 Sweden, 734b7456-6afc-4ba5-9eb1-e44eb712b188 Estonia, 7c8972af-46d8-45d8-9928-ca11c959706a Bulgaria, 84993a02-0bda-48c2-a072-0f582e778ff3 Hungary, 9601f0fb-71c8-46d6-901c-b0c11e41b94c Germany, 98705313-f7c3-4ad9-bc8e-c866590c7b4c Germany, a46c12be-e940-4ade-9322-97a2ddebbaed Portugal, a7d57835-a734-4c2d-9f77-81733f7491bf Hungary, ced2cf36-a96f-4b81-ac85-517042ee7ef1 Germany, d73af370-e733-4369-9550-2ae47c351b48 Poland, d8506a36-85a5-4e05-9a69-9b4c090cc148 Spain, e079558d-a47b-4f28-8edf-f04ab44fd258 France, e7f3ccdd-9d79-4c97-84ad-b4c479119f1b Poland, ef546eb4-0fda-49d8-947c-db988a7a5730 Czech Republic, f3952e38-6433-4473-9a54-aee6eac8f612 Denmark |
| Toxic Substances Control Act - TSCA | 2CMT2023-006524 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) cm |
Certificates and Declarations
| CQC Certificate | CN: CQC2014010304744407 / SE: CQC2014010304724379 |
| Declaration of Conformity - CCC | CN: 2020980304001092 / SE: 2020980304001485 |
| Declaration of Conformity - CE | 2CMT005209 |
| DNV Certificate | TAE000087N |
Container Information
| Package Level 1 Width | 263 mm mm |
| Package Level 1 Depth / Length | 323 mm mm |
| Package Level 1 Height | 454 mm mm |
| Package Level 1 Gross Weight | 8.7 kg kg |
| Package Level 1 EAN | 7320500501467 |
| Package Level 1 Units | box 1 piece |
External Classifications and Standards
| Object Classification Code | Q |
| ETIM 7 | EC000640 - Soft starter |
| ETIM 8 | EC000640 - Soft starter |
| ETIM 9 | EC000640 - Soft starter |
| eClass | V11.0 : 27370907 |
| UNSPSC | 39121521 |
| IDEA Granular Category Code (IGCC) | 4740 >> Soft starter |
