ABB GHV2501902R0002
RV-BC6/60 Varistor Surge Suppressor 24 … 60 V DC, screw terminal
- MPN
- GHV2501902R0002
- EAN
- 4013614027154
- Category
- ABB Mini Contactors
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the ABB GHV2501902R0002?
The RV-BC6/250 is a varistor surge suppressor for contactor coils. Designed to reduce the maximum overvoltage peak value and to limit or even completely eliminate the high pre-damping voltage frequencies for a rated control circuit voltage between 24 ... 60 V. The surge suppressor is equipt with screw terminals and can be mounted on the DC-operated B6 and B7 mini contactor.
Specifications
General
| Order code (ABB product ID) | GHV2501902R0002 |
| Type | RV-BC6/60 |
| Lifecycle | Active (current ABB product) |
| Country of origin | Germany |
Ordering
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389099 |
Dimensions
| Product Net Width | 21 mm |
| Product Net Depth / Length | 12 mm |
| Product Net Height | 11.5 mm |
| Product Net Weight | 0.005 kg |
Technical
| Standards | UL 60947-1, UL 60947-4-1 |
| Rated Frequency (f) | Control Circuit DC |
| Rated Insulation Voltage (U<sub>i</sub>) | 690 V |
| Rated Control Circuit Voltage (U<sub>c</sub>) | DC Operation 24 ... 60 V DC |
| Degree of Protection | IP20 |
| Terminal Type | Screw Terminals |
| Suitable For | BC6, BC7, KC6, TBC7, TKC6, VBC6, VBC6A, VBC7, VBC7A |
| Suitable for Product Class | Mini Contactors |
| Product Name | Surge Suppressor |
Environmental
| Ambient Air Temperature | Operation -25 ... +55 °C, Storage -40 ... +80 °C |
| Maximum Operating Altitude Permissible | 2000 m |
Material Compliance
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
External Classifications and Standards
| Object Classification Code | F |
| ETIM 7 | EC000197 - Surge voltage protection |
| ETIM 8 | EC000683 - Surge protection module |
| ETIM 9 | EC000683 - Surge protection module |
| eClass | V11.0 : 27371010 |
| UNSPSC | 39121610 |
| IDEA Granular Category Code (IGCC) | 4906 >> Surge suppressers |
| E-Number (Norway) | 4188186 |
| E-Number (Sweden) | 3210693 |
