ABB ACS280-04S-07A2-4

Name: ABB ACS280-04S-07A2-4
Brand: ABB
SKU: ACS280-04S-07A2-4

MPN: ACS280-04S-07A2-4 · Brand: ABB

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	ACS280
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	1.32 kg

Shipping & availability

When can ACS280-04S-07A2-4 be shipped?

ACS280-04S-07A2-4 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up ACS280-04S-07A2-4 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for ACS280-04S-07A2-4 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ACS280-04S-07A2-4, subject to availability and destination.

ACS280-04S-07A2-4 PN:3kW, IN:7.2A

Specifications

Ordering

Customs Tariff Number	85044087
HS Code	850440 -- ELECTRICAL MACHINERY AND EQUIPMENT AND PARTS THEREOF; SOUND RECORDERS AND REPRODUCERS, TELEVISION IMAGE AND SOUND RECORDERS AND REPRODUCERS, AND PARTS AND ACCESSORIES OF SUCH ARTICLES;Electrical transformers, static converters (for example, rectifiers) and inductors;Static converters
Invoice Description	ACS280-04S-07A2-4 PN:3kW, IN:7.2A
Made To Order	No
Minimum Order Quantity	10 piece
Order Multiple	10 piece
Quote Only	No
Selling Unit of Measure	piece

Dimensions

Product Net Weight	1.32 kg kg
Product Net Depth / Length	90 mm mm
Product Net Height	196 mm mm
Product Net Width	141 mm mm
Package Level 1 Depth / Length	341 mm mm
Package Level 1 Height	225 mm mm
Package Level 1 Width	575 mm mm
Package Level 1 Units	10 carton

Technical

Number of Phases	3-phase
Degree of Protection	IP00
Enclosure Type NEMA	Open Type
Frequency (f)	47.5 ... 63 Hz Hz
Frame Size	R2
Input Voltage (Uin)	380 ... 480 V V
Mounting Type	Module
Output Current, Normal Use (In)	7.2 A A
Output Current, Light-Overload Use (ILD)	6.8 A A
Output Current, Heavy-Duty Use (IHD)	5.6 A A
Output Power, Normal Use (Pn)	3 kW kW
Output Power, Light-Overload Use (PLD)	3 kW kW
Output Power, Heavy-Duty Use (PHD)	2.2 kW kW
Efficiency Level	IE2
