ACS180-04N-05A6-4

Name: ACS180-04N-05A6-4
Brand: ABB
SKU: 3AXD50000716531

MPN: 3AXD50000716531 · Brand: ABB

Price on request

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	ACS180
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	1.24 kg

Shipping & availability

When can 3AXD50000716531 be shipped?

3AXD50000716531 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 3AXD50000716531 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 3AXD50000716531 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3AXD50000716531, subject to availability and destination.

The ACS180 is a compact, robust, and adaptable variable speed drive (VSD) for applications such as pumps, fans, compressors, conveyors, winders and mixers. This easy-to-use compact VSD offers excellent performance and quality at superior value with all essential machinery application features embedded. And as a member of ABB’s all-compatible drives portfolio, it shares the same architecture and user interfaces for ease of use.

Specifications

Ordering

Customs Tariff Number	85044087
HS Code	850440 -- ELECTRICAL MACHINERY AND EQUIPMENT AND PARTS THEREOF; SOUND RECORDERS AND REPRODUCERS, TELEVISION IMAGE AND SOUND RECORDERS AND REPRODUCERS, AND PARTS AND ACCESSORIES OF SUCH ARTICLES;Electrical transformers, static converters (for example, rectifiers) and inductors;Static converters
Invoice Description	ACS180-04N-05A6-4 PN: 2.2 kW, IN: 5.6 A kW
Made To Order	Yes
Minimum Order Quantity	1 piece
Order Multiple	1 piece
Quote Only	No
Selling Unit of Measure	piece

Dimensions

Product Net Weight	1.24 kg, 2.734 lb kg
Product Net Depth / Length	143 mm, 5.630 in mm
Product Net Height	220 mm, 8.661 in mm
Product Net Width	70 mm, 2.756 in mm
Package Level 1 Depth / Length	225 mm, 8.858 in mm
Package Level 1 Height	115 mm, 4.528 in mm
Package Level 1 Width	220 mm, 8.661 in mm
Package Level 1 Units	1 carton

Technical

Number of Phases	3-phase
Degree of Protection	IP20
Enclosure Type NEMA	Open Type
Altitude	2000 m m
Operating Humidity (RHamb)	5 ... 95
Power Factor	0.98
Sound dB (A)	50.9 dB(A) A
Multiple Battery Information	No battery / cell included
Frequency (f)	47 ... 63 Hz Hz
Frame Size	R1
Input Voltage (Uin)	380 ... 480 V V
Mounting Type	Module
Communication Protocol	MODBUS
Number of Hardware Interfaces	Industrial Ethernet 0, Other 1, Parallel 0, PROFINET 0, RS-232 0, RS-422 0, RS-485 1, Serial TTY 0, USB 0
Includes	Control unit, PC connection
Analog Inputs	2
Analog Outputs	1
Number of Digital In/Outputs	4 / 2
Output Current, Normal Use (In)	5.6 A A
Output Current, Light-Overload Use (ILD)	5.3 A A
Output Current, Heavy-Duty Use (IHD)	4.0 A A
Output Power, Normal Use (Pn)	2.2 kW kW
Output Power, Light-Overload Use (PLD)	2.2 kW kW
Output Power, Heavy-Duty Use (PHD)	1.5 kW kW
Apparent Power Output	3.9 kV·A A
Efficiency Level	IE2
Standby Loss	9 W W
Temperature Rating	Maximum 40 °C

Technical UL

Output Current, Heavy-Duty Use (UL)	3.5 A A
Output Current, Light-Overload Use (UL)	4.8 A A
Output Power, Heavy-Duty Use (UL)	2 Hp
Output Power, Light-Overload Use (UL)	3 Hp

Certificates and Declarations

REACH Date	20250905
REACH Declaration	9AKK107992A7060
REACH Information	True - contains substances > 0.1 mass percentage
RoHS Date	20250106
RoHS Declaration	3AXD10001117584
RoHS Information	Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
