ACS880-04-470A-7
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | ACS880-04 |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 199 kg |
Shipping & availability
When can 3ABD00039522-D be shipped?
3ABD00039522-D is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 3ABD00039522-D in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 3ABD00039522-D and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3ABD00039522-D, subject to availability and destination.
The ACS880-04 drives are customized to meet the particular needs of specific industries, such as oil and gas, mining, metals, chemicals, cement, power plants, material handling, pulp and paper, sawmills, marine, water and wastewater, food and beverage, and automotive. They can control a wide range of applications, including cranes, extruders, winches, winders, conveyors, mixers, compressors, centrifuges, test benches, elevators, extruders, pumps, and fans. The ACS880-04 modules have all the essential features built-in, including a choke for harmonic filtering as standard, and options such as a brake chopper, EMC filter and communication protocol adapter, functional safety and I/O extension modules. The all built-in design combined with IP20 protection significantly simplifies engineering. The drive’s compact size, flexible cabling directions and versatile mounting possibilities from narrow bookshelf to flat mounting and horizontal mounting make it an ideal fit for almost any enclosure. The control unit with I/O and communication connections can be mounted outside the power module or integrated into it.
Specifications
Ordering
| Customs Tariff Number | 85044087 |
| HS Code | 850440 -- ELECTRICAL MACHINERY AND EQUIPMENT AND PARTS THEREOF; SOUND RECORDERS AND REPRODUCERS, TELEVISION IMAGE AND SOUND RECORDERS AND REPRODUCERS, AND PARTS AND ACCESSORIES OF SUCH ARTICLES;Electrical transformers, static converters (for example, rectifiers) and inductors;Static converters |
| Invoice Description | ACS880-04-470A-7 PN:450KW, IN:470A |
| Made To Order | No |
| Minimum Order Quantity | 1 piece |
| Order Multiple | 1 piece |
| Quote Only | No |
| Selling Unit of Measure | piece |
Dimensions
| Product Net Weight | 199 kg kg |
| Product Net Depth / Length | 506 mm mm |
| Product Net Height | 1741 mm mm |
| Product Net Width | 350 mm mm |
| Package Level 1 Depth / Length | 2050 mm mm |
| Package Level 1 Height | 690 mm mm |
| Package Level 1 Width | 645 mm mm |
| Package Level 1 Units | 1 carton |
Technical
| Number of Phases | 3-phase |
| Degree of Protection | IP20 |
| Enclosure Type NEMA | Open Type |
| Frequency (f) | 47.5 ... 63 Hz Hz |
| Frame Size | R11 |
| Input Voltage (Uin) | 525 … 690 V V |
| Mounting Type | Module_NO UNIT$ |
| Output Current, Normal Use (In) | 470 A A |
| Output Current, Light-Overload Use (ILD) | 455 A A |
| Output Current, Heavy-Duty Use (IHD) | 415 A A |
| Output Power, Normal Use (Pn) | 450 kW kW |
| Output Power, Light-Overload Use (PLD) | 450 kW kW |
| Output Power, Heavy-Duty Use (PHD) | 400 kW kW |
| Efficiency Level | IE2 |
Environmental
| WEEE Category | 4. Large Equipment (Any External Dimension More Than 50 cm) cm |
External Classifications and Standards
| UNSPSC | 39122001 |
