Rotary vane variable displacement pumps Parts
Compare Rotary vane variable displacement pumps
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Size [cm³] | Operating pressure, max. [bar] | Max. flow [l/min] | Weight [kg] |
|---|---|---|---|---|
| R901567375 | 25 | 100.0 | 45.0 | 11.34 |
| R901567181 | 25 | 100.0 | 45.0 | 11.38 |
| R901567374 | 25 | 50.0 | 45.0 | 11.31 |
| R901567373 | 25 | 50.0 | 45.0 | 13.34 |
| R901567200 | 25 | 50.0 | 45.0 | 11.5 |
| R901567372 | 25 | 50.0 | 45.0 | 11.31 |
| R901567371 | 25 | 50.0 | 45.0 | 12 |
| R901567180 | 25 | 50.0 | 45.0 | 11.34 |
| R901567171 | 20 | 100.0 | 36.0 | 11.4 |
| R901567170 | 20 | 50.0 | 36.0 | 11.36 |
| R901567370 | 14 | 70.0 | 25.2 | 5.18 |
| R901567161 | 14 | 70.0 | 25.2 | 5.15 |
| R901567369 | 14 | 40.0 | 25.2 | 5.53 |
| R901567160 | 14 | 40.0 | 25.2 | 5.53 |
| R901567368 | 10 | 100.0 | 18.0 | 5.2 |
| R901567367 | 10 | 100.0 | 18.0 | 5.62 |
| R901567366 | 10 | 100.0 | 18.0 | 5.62 |
| R901567192 | 10 | 100.0 | 18.0 | 5.2 |
| R901567151 | 10 | 100.0 | 18.0 | 5.26 |
| R901567365 | 10 | 50.0 | 18.0 | 5.57 |
| R901567191 | 10 | 50.0 | 18.0 | 5.12 |
| R901567364 | 10 | 50.0 | 18.0 | 5.57 |
| R901567363 | 10 | 50.0 | 18.0 | 5.57 |
| R901567362 | 10 | 50.0 | 18.0 | 5.57 |
Common to all listed parts
| Displacement type | variable |
| Product family | PV7-AX...A |
| Through-drive | without |
| Direction of rotation | clockwise rotation |
| Hydraulic fluid | HLP; HLPD; HVLP; HVLPD |
| Seals | NBR |
