Compensated directional control valves Parts
Compare Compensated directional control valves
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Connector Type | Control Signal | De-Stroke Reaction A | De-Stroke Reaction B | Digital Type |
|---|---|---|---|---|---|
| 157B4274 | 1x4 AMP JPT SAAB | On/Off | 225 ms | 225 ms | N/A |
| 157B4266 | 1x4 DIN 43650-A/ISO4400 | On/Off | 90 ms | 90 ms | N/A |
| 157B4227 | 1x3 Deutsch-DT04 | On/Off | 225 ms | 225 ms | N/A |
| 157B4217 | 1x4 DIN 43650-A/ISO4400 | On/Off | 225 ms | 225 ms | N/A |
| 157B4096 | 2x4 Deutsch - DT04 | Ratiometric | 120 ms | 120 ms | N/A |
| 157B4092 | 1x4 Deutsch - DT04 | Ratiometric | 120 ms | 120 ms | N/A |
| 11362130 | 2x4 AMP JPT SAAB | CANBus | 120 ms | 120 ms | CC Preset |
| 11361496 | 2x4 AMP JPT SAAB | CANBus | 120 ms | 120 ms | CC Preset |
| 11361477 | 2x4 AMP JPT SAAB | CANBus | 120 ms | 120 ms | CC Preset |
| 11361476 | 2x4 AMP JPT SAAB | CANBus | 120 ms | 120 ms | CC4 |
| 11349922 | 2x4 AMP JPT SAAB | CANBus | 120 ms | 120 ms | CC Preset |
| 11349898 | 2x4 AMP JPT SAAB | CANBus | 120 ms | 120 ms | CC |
| 11349881 | 2x4 AMP JPT SAAB | CANBus | 120 ms | 120 ms | CC Preset |
Common to all listed parts
| A Port Placement | N/A |
| B Port Placement | N/A |
| Certification | ISO13849 Compliant |
| Coil Power | 8 W |
| Ex Application | N/A |
| Extra Function | N/A |
| Manual Override | N/A |
| Maximum System Pressure Peaks | 60 |
