Schneider Electric
ATV71PU55N4ZVariable speed drive ATV71-baseplate-5.5kW-7.5HP-480V-EMCfilter-w/o graphicterm.
Altivar 71 Parts
Schneider Electric
ATV71PU40N4ZVariable speed drive ATV71-base plate-4kW-5HP-480V-EMC filter-w/o graphic term.
Schneider Electric
ATV71PU30N4ZVariable speed drive ATV71-base plate -3kW-480V -EMC filter-w/o graphic terminal
Schneider Electric
ATV71PU22N4ZVariable speed drive ATV71-baseplate-2.2kW-3HP-480V-EMC filter-w/o graphic term.
Schneider Electric
ATV71PU15N4ZVariable speed drive ATV71-baseplate-1.5kW-2HP-480V-EMC filter-w/o graphic term.
Schneider Electric
ATV71PD11N4ZVariable speed drive ATV71-baseplate-11kW-15HP-480V-EMC filter-w/o graphic term.
Schneider Electric
ATV71P075N4ZVariable speed drive ATV71-baseplate-0.75kW-1HP-480V-EMCfilter-w/o graphic term.
Schneider Electric
ATV71LU75N4ZVariable speed drive ATV71 - 7.5kW-10HP - 480V - EMC filter-w/o graphic terminal
Schneider Electric
ATV71LU75M3ZVariable speed drive ATV71 - 5.5kW-7.5HP - 240V - EMCfilter-w/o graphic terminal
Schneider Electric
ATV71LU55N4ZVariable speed drive ATV71 - 5.5kW-7.5HP - 480V - EMCfilter-w/o graphic terminal
Schneider Electric
ATV71LU55M3ZVariable speed drive ATV71 - 4kW-5HP - 240V - EMC filter-w/o graphic terminal
Schneider Electric
ATV71LU40N4ZVariable speed drive ATV71 - 4kW-5HP - 480V - EMC filter-w/o graphic terminal
Schneider Electric
ATV71LU40M3ZVariable speed drive ATV71 - 3kW-5HP - 240V - EMC filter-w/o graphic terminal
Schneider Electric
ATV71LU30N4ZVariable speed drive ATV71 - 3kW-480V - EMC filter-w/o graphic terminal
Schneider Electric
ATV71LU22M3ZVariable speed drive ATV71 - 1.5kW-2HP - 240V - EMC filter-w/o graphic terminal
Schneider Electric
ATV71LU30M3ZVariable speed drive ATV71 - 2.2kW-3HP - 240V - EMC filter-w/o graphic terminal
Schneider Electric
ATV71LD75N4ZVariable speed drive ATV71 - 75kW-100HP - 480V - EMC filter-w/o graphic terminal
Schneider Electric
ATV71LD66M3ZVariable speed drive Altivar Lift, 15 kW 20 Hp, 200...240 V three-phase, with heat sink
Schneider Electric
ATV71LD55N4ZVariable speed drive ATV71 - 55kW-75HP - 480V - EMC filter-w/o graphic terminal
Schneider Electric
ATV71LD54M3ZVariable speed drive Altivar Lift, 11 kW 15 Hp, 200...240 V three-phase, with heat sink
Schneider Electric
ATV71LD48N4ZVariable speed drive Altivar Lift, 22 kW 30 Hp, 380...480 V three-phase, EMC filter, with heat sink
Schneider Electric
ATV71LD45N4ZVariable speed drive Altivar Lift, 45 kW 60 Hp, 380...480 V three-phase, EMC filter, with heat sink
Schneider Electric
ATV71LD37N4ZVariable speed drive ATV71 - 37kW-50HP - 480V - EMC filter-w/o graphic terminal
Schneider Electric
ATV71LD33N4ZVariable speed drive Altivar Lift, 15 kW 20 Hp, 380...480 V three-phase, EMC filter, with heat sink
Compare Altivar 71
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Range of product | Network number of phases | Nominal switching frequency | Noise level | Product certifications |
|---|---|---|---|---|---|
| ATV71PU55N4Z | Altivar 71 | 3 phases | 4 kHz | 0 dB conforming to 86/188/EEC | UL; C-Tick; CSA; NOM 117 |
| ATV71PU40N4Z | Altivar 71 | 3 phases | 4 kHz | 0 dB conforming to 86/188/EEC | NOM 117; C-Tick; CSA; UL |
| ATV71PU30N4Z | Altivar 71 | 3 phases | 4 kHz | 0 dB conforming to 86/188/EEC | C-Tick; UL; CSA; NOM 117 |
| ATV71PU22N4Z | Altivar 71 | 3 phases | 4 kHz | 0 dB conforming to 86/188/EEC | UL; CSA; C-Tick; NOM 117 |
| ATV71PU15N4Z | Altivar 71 | 3 phases | 4 kHz | 0 dB conforming to 86/188/EEC | NOM 117; UL; CSA; C-Tick |
| ATV71PD11N4Z | Altivar 71 | 3 phases | 4 kHz | 0 dB conforming to 86/188/EEC | C-Tick; NOM 117; UL; CSA |
| ATV71P075N4Z | Altivar 71 | 3 phases | 4 kHz | 0 dB conforming to 86/188/EEC | C-Tick; UL; CSA; NOM 117 |
| ATV71LU75N4Z | Altivar 71 | 3 phases | 4 kHz | 55.6 dB conforming to 86/188/EEC | CSA; NOM 117; C-Tick; GOST; UL |
| ATV71LU75M3Z | Altivar 71 | 3 phases; Single phase | 4 kHz | 57.4 dB conforming to 86/188/EEC | C-Tick; CSA; NOM 117; UL; GOST |
| ATV71LU55N4Z | Altivar 71 | 3 phases | 4 kHz | 55.6 dB conforming to 86/188/EEC | CSA; C-Tick; UL; GOST; NOM 117 |
| ATV71LU55M3Z | Altivar 71 | Single phase; 3 phases | 4 kHz | 55.6 dB conforming to 86/188/EEC | CSA; C-Tick; GOST; NOM 117; UL |
| ATV71LU40N4Z | Altivar 71 | 3 phases | 4 kHz | 54.5 dB conforming to 86/188/EEC | C-Tick; CSA; NOM 117; UL; GOST |
| ATV71LU40M3Z | Altivar 71 | Single phase; 3 phases | 4 kHz | 54.5 dB conforming to 86/188/EEC | UL; CSA; C-Tick; NOM 117; GOST |
| ATV71LU30N4Z | Altivar 71 | 3 phases | 4 kHz | 54.5 dB conforming to 86/188/EEC | UL; C-Tick; CSA; GOST; NOM 117 |
| ATV71LU22M3Z | Altivar 71 | 3 phases; Single phase | 4 kHz | 54.5 dB conforming to 86/188/EEC | NOM 117; GOST; UL; C-Tick; CSA |
| ATV71LU30M3Z | Altivar 71 | 3 phases; Single phase | 4 kHz | 54.5 dB conforming to 86/188/EEC | CSA; GOST; NOM 117; UL; C-Tick |
| ATV71LD75N4Z | Altivar 71 | 3 phases | 2.5 kHz | 63.7 dB conforming to 86/188/EEC | CSA; UL; NOM 117; C-Tick |
| ATV71LD66M3Z | Altivar Lift | 3 phases | 8 kHz | 60.2 dB conforming to 86/188/EEC | C-Tick; CSA; UL; NOM 117; GOST |
| ATV71LD55N4Z | Altivar 71 | 3 phases | 2.5 kHz | 63.7 dB conforming to 86/188/EEC | C-Tick; UL; CSA; NOM 117 |
| ATV71LD54M3Z | Altivar Lift | 3 phases | 8 kHz | 60.2 dB conforming to 86/188/EEC | UL; CSA; C-Tick; NOM 117; GOST |
| ATV71LD48N4Z | Altivar Lift | 3 phases | 8 kHz | 59.9 dB conforming to 86/188/EEC | UL; NOM 117; CSA; C-Tick |
| ATV71LD45N4Z | Altivar Lift | 3 phases | 8 kHz | 59.9 dB conforming to 86/188/EEC | C-Tick; CSA; NOM 117; UL |
| ATV71LD37N4Z | Altivar 71 | 3 phases | 2.5 kHz | 64 dB conforming to 86/188/EEC | NOM 117; UL; C-Tick; CSA |
| ATV71LD33N4Z | Altivar Lift | 3 phases | 8 kHz | 60.2 dB conforming to 86/188/EEC | C-Tick; CSA; GOST; UL; NOM 117 |
Common to all listed parts
| Product or component type | Variable speed drive |
| Type of polarization | No impedance for Modbus |
| Regulation loop | Adjustable PI regulator |
| Output voltage | <= power supply voltage |
| Insulation | Electrical between power and control |
| Analogue input number | 2 |
| Linearity error | +/- 0.15 % of maximum value (AI1-/Al1+, AI2); +/- 0.2 % (AO1) |
| Analogue output number | 1 |
