Mitsubishi Low-voltage switchgear – DC Interface Contactors Parts
Compare Mitsubishi Low-voltage switchgear – DC Interface Contactors
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Product Specification | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V | Contact Arrangements (Valid): Auxiliary Contact (Standard) |
|---|---|---|---|---|---|
| SD-QR19 | DC Operated Interface Contactor | 3.7 | 5.5 | 5.5 | 1NO1NC×2 |
| SD-QR12 | DC Operated Interface Contactor | 2.5 | 4 | 4 | 1NO1NC×2 |
| SD-QR11 | DC Operated Interface Contactor | 2.5 | 4 | 4 | 1NC×2 |
| SD-Q19 | DC Operated Interface Contactor | 3.7 | 5.5 | 5.5 | 1NO1NC |
| SD-Q12 | DC Operated Interface Contactor | 2.5 | 4 | 4 | 1NO1NC |
| SD-Q11 | DC Operated Interface Contactor | 2.5 | 4 | 4 | 1NO |
| MSOD-QR12BCKP | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NO1NC×2 |
| MSOD-QR11BCKP | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NC×2 |
| MSOD-QR12BC | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NO1NC×2 |
| MSOD-QR11BC | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NC×2 |
| MSOD-QR19KP | DC Operated DC Interface Contactors | 3.7 | 5.5 | 5.5 | 1NO1NC×2 |
| MSOD-QR12KP | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NO1NC×2 |
| MSOD-QR11KP | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NC×2 |
| MSOD-QR19 | DC Operated DC Interface Contactors | 3.7 | 5.5 | 5.5 | 1NO1NC×2 |
| MSOD-QR12 | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NO1NC×2 |
| MSOD-QR11 | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NC×2 |
| MSOD-Q12BCKP | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NO1NC |
| MSOD-Q11BCKP | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NO |
| MSOD-Q12BC | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NO1NC |
| MSOD-Q11BC | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NO |
| MSOD-Q19KP | DC Operated DC Interface Contactors | 3.7 | 5.5 | 5.5 | 1NO1NC |
| MSOD-Q12KP | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NO1NC |
| MSOD-Q11KP | DC Operated DC Interface Contactors | 2.5 | 4 | 4 | 1NO |
| MSOD-Q19 | DC Operated DC Interface Contactors | 3.7 | 5.5 | 5.5 | 1NO1VC |
Common to all listed parts
| Series | Low-voltage switchgear |
| Rated Insulation Voltage Ui [V] | 690 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V | 3 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V | 1 |
| Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V | 0.6 |
| Auxiliary Contact Rated Operating Current [A]: DC Resistive Load (Category DC-12): DC24V | 10 |
| Auxiliary Contact Conventional Free Air Thermal Current [A] | 10 |
| Auxiliary Contact Minimal Applicable Load | 5V 3mA |
