Mitsubishi Low-voltage switchgear – Thermal Overload Relays Parts
Compare Mitsubishi Low-voltage switchgear – Thermal Overload Relays
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Adjustment Range of Setting Current [A] | Heater Designation [A]: Category-1 | Terminal Screw Size: Main Circuit (Load Side) | Heater Designation [A]: Category-2 | Combined Magnetic Contactor Frame: Category-1 |
|---|---|---|---|---|---|
| TH-N600KPSR | 200 to 800 | 250 to 660 | M4 | — | — |
| TH-N600SR | 200 to 800 | 250 to 660 | M4 | — | — |
| TH-N400HZKPSR | 85 to 400 | 105 to 250 | M12 | 330 | — |
| TH-N400RHKPSR | 85 to 400 | 105 to 250 | M12 | 330 | N300,N400 |
| TH-N400HZSR | 85 to 400 | 105 to 250 | M12 | 330 | — |
| TH-N400RHSR | 85 to 400 | 105 to 250 | M12 | 330 | N300,N400 |
| TH-N220HZKPSR | 65 to 220 | 82 to 150 | M10 | 180 | — |
| TH-N220RHKPSR | 65 to 220 | 82 to 150 | M10 | 180 | N180,N220 |
| TH-N220HZSR | 65 to 220 | 82 to 150 | M10 | 180 | — |
| TH-N220RHSR | 65 to 220 | 82 to 150 | M10 | 180 | N180,N220 |
| TH-N120TAKPSR | 85 to 150 | 105 | M8 | 125 | N125,N150 |
| TH-N120TASR | 85 to 150 | 105 | M8 | 125 | N125,N150 |
| TH-N120KPSR | 34 to 100 | 42 to 82 | M8 | — | N125,N150 |
| TH-N120SR | 34 to 100 | 42 to 82 | M8 | — | N125,N150 |
| TH-N60TAKPSR | 54 to 100 | 67 | M6 | 82 | N80,N95 |
| TH-N60TASR | 54 to 100 | 67 | M6 | 82 | N80,N95 |
| TH-N60TAKF | 54 to 93 | 67 | M6 | 82 | N80,N95 |
| TH-N60TAFS | 54 to 93 | 67 | M6 | 82 | N80,N95 |
| TH-N60KPSR | 12 to 65 | 15 to 42 | M6 | 54 | N50,N65,N80,N95 |
| TH-N60SR | 12 to 65 | 15 to 42 | M6 | 54 | N50,N65,N80,N95 |
| TH-N60KF | 34 to 65 | 42 | M6 | 54 | N50,N65,N80,N95 |
| TH-N60FS | 34 to 65 | 42 | M6 | 54 | N50,N65,N80,N95 |
| TH-N20TACXKPSR | 18 to 34 | 22 | M5 | 29 | N25,N35 |
| TH-N20TAKPSR | 18 to 34 | 22 | M5 | 29 | N25,N35 |
Common to all listed parts
| Series | Low-voltage switchgear |
| Rated Insulation Voltage Ui [V] | 690 |
| Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC24V | 2 |
| Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC120V | 2 |
| Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC240V | 1 |
| Rated Operating Current [A]: AC Coil Load (Category AC-15) Make Contact: AC550V | 0.5 |
| Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC24V | 3 |
| Rated Operating Current [A]: AC Coil Load (Category AC-15) Break Contact: AC120V | 3 |
