Mitsubishi Low-voltage switchgear – Contactor Relays Parts
Compare Mitsubishi Low-voltage switchgear – Contactor Relays
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Product Specification | Rated Insulation Voltage Ui [V] | Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V | Contact Arrangements (Valid) | Mechanical Durability [Mil.Times] |
|---|---|---|---|---|---|
| SR-N8DL | Delay Open Type | 690 | 3 | 6NO,5NO1NC,4NO2NC | 250 |
| SR-N4DL | Delay Open Type | 690 | 3 | 2NO,1NO1NC | 250 |
| SR-T9DL | Delay Open Type | 690 | 3 | 6NO1NC,4NO3NC | 50 |
| SR-T5DL | Delay Open Type | 690 | 3 | 2NO1NC | 50 |
| SRD-N8CXLCSA | DC Operated Overlap Contact | 600 | 5 | 7NO1NC,6NO2NC,4NO4NC | 100 |
| SRD-N5CXLCSA | DC Operated Overlap Contact | 600 | 5 | 4NO1NC,3NO2NC | 100 |
| SRD-N4CXLCSA | DC Operated Overlap Contact | 600 | 5 | 3NO1NC,2NO2NC | 100 |
| SRD-N8LCSA | DC Operated Overlap Contact | 600 | 5 | 7NO1NC,6NO2NC,4NO4NC | 100 |
| SRD-N5LCSA | DC Operated Overlap Contact | 600 | 5 | 4NO1NC,3NO2NC | 100 |
| SRD-N4LCSA | DC Operated Overlap Contact | 600 | 5 | 3NO1NC,2NO2NC | 100 |
| SRD-N8CXLC | DC Operated Overlap Contact | 600 | 5 | 6NO2NC,4NO4NC | 100 |
| SRD-N5CXLC | DC Operated Overlap Contact | 600 | 5 | 4NO1NC,3NO2NC | 100 |
| SRD-N4CXLC | DC Operated Overlap Contact | 600 | 5 | 3NO1NC,2NO2NC | 100 |
| SRD-K100LC | DC Operated Overlap Contact | 600 | 5 | 8NO2NC,6NO4NC,5NO5NC | 100 |
| SRD-N8LC | DC Operated Overlap Contact | 600 | 5 | 7NO1NC,6NO2NC,4NO4NC | 100 |
| SRD-N5LC | DC Operated Overlap Contact | 600 | 5 | 4NO1NC,3NO2NC | 100 |
| SRD-N4LC | DC Operated Overlap Contact | 600 | 5 | 3NO1NC,2NO2NC | 100 |
| SR-N8CXLCSA | AC Operated Overlap Contact | 600 | 5 | 7NO1NC,6NO2NC,4NO4NC | 100 |
| SR-N5CXLCSA | AC Operated Overlap Contact | 600 | 5 | 4NO1NC,3NO2NC | 100 |
| SR-N4CXLCSA | AC Operated Overlap Contact | 600 | 5 | 3NO1NC,2NO2NC | 100 |
| SR-N8LCSA | AC Operated Overlap Contact | 600 | 5 | 7NO1NC,6NO2NC,4NO4NC | 100 |
| SR-N5LCSA | AC Operated Overlap Contact | 600 | 5 | 4NO1NC,3NO2NC | 100 |
| SR-N4LCSA | AC Operated Overlap Contact | 600 | 5 | 3NO1NC,2NO2NC | 100 |
| SR-N8CXLC | AC Operated Overlap Contact | 600 | 5 | 7NO1NC,6NO2NC,4NO4NC | 100 |
Common to all listed parts
| Series | Low-voltage switchgear |
| Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V | 6 |
| Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC440V | 5 |
| Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC550V | 5 |
| Rated Operating Current [A]: DC Coil Load (Category DC-13) Single-Pole: DC24V | 3 |
| Making Current Capacity [A]: Category AC-15: AC120V | 66 |
| Making Current Capacity [A]: Category AC-15: AC240V | 55 |
| Making Current Capacity [A]: Category AC-15: AC550V | 33 |
