Mitsubishi Low-voltage switchgear – Magnetic Contactors Parts
Compare Mitsubishi Low-voltage switchgear – Magnetic Contactors
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V | Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V | Main Contact Rated Operating Current [A]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V | Main Contact Conventional Free Air Thermal Current [A] |
|---|---|---|---|---|---|
| SHLD-V400 | 95 | 200 | 400 | 400 | 450 |
| SHLD-V320 | 75 | 150 | 320 | 320 | 350 |
| SHLD-V160 | 45 | 90 | 180 | 180 | 200 |
| SHL-V400 | 95 | 200 | 400 | 400 | 450 |
| SHL-V320 | 75 | 150 | 320 | 320 | 350 |
| SHL-V160 | 45 | 90 | 180 | 180 | 200 |
| SHD-V400 | 95 | 200 | 400 | 400 | 450 |
| SHD-V320 | 75 | 150 | 320 | 320 | 350 |
| SHD-V160 | 45 | 90 | 180 | 180 | 200 |
| SH-V600 | 160 | 300 | 630 | 630 | 750 |
| SH-V400 | 95 | 200 | 400 | 400 | 450 |
| SH-V320 | 75 | 150 | 320 | 320 | 350 |
| SH-V160 | 45 | 90 | 180 | 180 | 200 |
| S-N35CXKG | 7.5 | 15 | 35 | 32 | 60 |
| S-N25CXKG | 5.5 | 11 | 26 | 25 | 50 |
| S-N21CXKG | 4 | 7.5 | 20 | 20 | 32 |
| S-N20CXKG | 4 | 7.5 | 20 | 20 | 32 |
| S-N11CXKG | 2.7 | 4 | 13 | 9 | 20 |
| S-N220KG | 55 | 110 | 220 | 220 | 260 |
| S-N125KG | 30 | 60 | 125 | 120 | 150 |
| S-N80KG | 19 | 37 | 80 | 80 | 135 |
| S-N65KG | 15 | 30 | 65 | 65 | 100 |
| S-N50KG | 11 | 22 | 50 | 48 | 80 |
| S-N35KG | 7.5 | 15 | 35 | 32 | 60 |
Common to all listed parts
| Series | Low-voltage switchgear |
| Auxiliary Contact Rated Operating Current [A]: DC Coil Load (Category DC-13): DC110V | 0.6 |
| Contact Arrangements (Valid): Main Contact (Standard) | 3NO |
