Mitsubishi Low-voltage switchgear – Magnetic Starters Parts
Compare Mitsubishi Low-voltage switchgear – Magnetic Starters
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC200 to 220V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC380 to 440V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Japan): AC500 to 550V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC220 to 240V | Main Contact Rating [Kw]: Three-Phase Squirrel-Cage Motor (Category AC-3)(Global): AC380 to 440V |
|---|---|---|---|---|---|
| MSO-N35CXKPSR | 7.5 | 15 | 15 | 11 | 18.5 |
| MSO-N25CXKPSR | 5.5 | 11 | 11 | 7.5 | 15 |
| MSO-N21CXKPSR | 4 | 7.5 | 7.5 | 5.5 | 11 |
| MSO-N20CXKPSR | 4 | 7.5 | 7.5 | 5.5 | 11 |
| MSO-N35CXSR | 7.5 | 15 | 15 | 11 | 18.5 |
| MSO-N25CXSR | 5.5 | 11 | 11 | 7.5 | 15 |
| MSO-N21CXSR | 4 | 7.5 | 7.5 | 5.5 | 11 |
| MSO-N20CXSR | 4 | 7.5 | 7.5 | 5.5 | 11 |
| MSO-N12CXSR | 2.7 | 4 | 5.5 | 3.5 | 5.5 |
| MSO-N11CXSR | 2.7 | 4 | 5.5 | 3.5 | 5.5 |
| MSO-N10CXSR | 2.2 | 2.7 | 2.7 | 2.5 | 4 |
| MSO-N35CXFS | 7.5 | 15 | 15 | 11 | 18.5 |
| MSO-N25CXFS | 5.5 | 11 | 11 | 7.5 | 15 |
| MSO-N21CXFS | 4 | 7.5 | 7.5 | 5.5 | 11 |
| MSO-N20CXFS | 4 | 7.5 | 7.5 | 5.5 | 11 |
| MSO-N35CXKF | 7.5 | 15 | 15 | 11 | 18.5 |
| MSO-N25CXKF | 5.5 | 11 | 11 | 7.5 | 15 |
| MSO-N21CXKF | 4 | 7.5 | 7.5 | 5.5 | 11 |
| MSO-N20CXKF | 4 | 7.5 | 7.5 | 5.5 | 11 |
| MSO-N12CXKF | 2.7 | 4 | 5.5 | 3.5 | 5.5 |
| MSO-N11CXKF | 2.7 | 4 | 5.5 | 3.5 | 5.5 |
| MSO-N10CXKF | 2.2 | 2.7 | 2.7 | 2.5 | 4 |
| MSO-N400KPSR | 110 | 200 | 200 | 125 | 220 |
| MSO-N300KPSR | 75 | 150 | 160 | 90 | 160 |
Common to all listed parts
| Series | Low-voltage switchgear |
| Main Contact Minimal Applicable Load | 48V 200mA |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC120V | 6 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC240V | 3 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC440V | 1.5 |
| Auxiliary Contact Rated Operating Current [A]: AC Coil Load (Category AC-15): AC550V | 1.2 |
| Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC120V | 10 |
| Auxiliary Contact Rated Operating Current [A]: AC Resistive Load (Category AC-12): AC240V | 8 |
