800R Hazardous Location Operators Parts
Compare 800R Hazardous Location Operators
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Enclosure compatibility (NEMA type) | Enclosure material | Number of push buttons | Operator cap type | Operator legend text |
|---|---|---|---|---|---|
| 800R-3HG4RW | 1, 4, 4X, 12, 13 | Glass filled Polyester (Rosite) | 3 | Booted head | START - JOG - STOP |
| 800R-4HA4RL | 1, 4, 4X, 12, 13 | Glass filled Polyester (Rosite) | 4 | Flush head | FULL - s - LOW - STOP |
| 800R-3TX2R | 1, 4, 12, 13 | Die cast Aluminum | 3 | Flush head | No legend (STOP on bottom) |
| 800R-3TX2Y | 1, 4, 12, 13 | Die cast Aluminum | 3 | Flush head | No legend (STOP on bottom) |
| 800R-3TX2P | 1, 4, 12, 13 | Die cast Aluminum | 3 | Flush head | No legend (STOP on bottom) |
| 800R-3HX2R4T | 1, 4, 4X, 12, 13 | Stainless Steel | 3 | Booted head | No legend (STOP on bottom) |
| 800R-3HX2R4RL | 1, 4, 4X, 12, 13 | Glass filled Polyester (Rosite) | 3 | Flush head | No legend (STOP on bottom) |
| 800R-3HX2R4R | 1, 4, 4X, 12, 13 | Glass filled Polyester (Rosite) | 3 | Booted head | No legend (STOP on bottom) |
| 800R-3HX2P4TL | 1, 4, 4X, 12, 13 | Stainless Steel | 3 | Flush head | No legend (STOP on bottom) |
Common to all listed parts
| Lifecycle | Active |
| Repair options available | No |
| Bottom button modification | None |
| Conduit entry | 3/4 in, 14 NPT |
| Contact block configuration | 1-NO 1-NC standard contacts |
| Contact block electrical design life (cycles, at max. load) | 1000000 |
| Contact block operational voltage, max | 600V AC @ 600V DC |
| Contact block termination tightening torque | 6 - 8 in-lb / 0.7 - 0.9 N-m |
