Back of Panel Components, 30 mm Parts
Compare Back of Panel Components, 30 mm
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Operator cap/button size | Operator cap color | Operator cap type | Operator lock key code |
|---|---|---|---|---|
| 800T-E1555M6D4 | 40 mm | Red | Mushroom head | Spring bolt key E102 |
| 800T-E1555J6A1 | 60 mm | Red | Jumbo mushroom head | Spring bolt key E102 |
| 800T-E1555M6 | 40 mm | Red | Mushroom head | Spring bolt key E102 |
| 800T-E1554M6A4 | 40 mm | Red | Mushroom head | Spring bolt key E101 |
| 800T-E1552M6A4 | 40 mm | Red | Mushroom head | Spring bolt key E144 |
| 800T-E1555J6A | 60 mm | Red | Jumbo mushroom head | Spring bolt key E102 |
| 800T-E1552M6D4 | 40 mm | Red | Mushroom head | Spring bolt key E144 |
| 800T-E1554J6A1 | 60 mm | Red | Jumbo mushroom head | Spring bolt key E101 |
| 800T-E1552J6A1 | 60 mm | Red | Jumbo mushroom head | Spring bolt key E144 |
| 800T-E1550M6D4 | 40 mm | Red | Mushroom head | Spring bolt key E108 |
| 800T-E1551A | N/A | N/A | Standard unit | Spring bolt key E132 |
| 800T-E1550M6A1 | 40 mm | Red | Mushroom head | Spring bolt key E108 |
| 800T-E1548M6D4 | 40 mm | Red | Mushroom head | Spring bolt key E120 |
| 800T-E1550J6 | 60 mm | Red | Jumbo mushroom head | Spring bolt key E108 |
| 800T-E1548A | N/A | N/A | Standard unit | Spring bolt key E120 |
| 800T-E1546M6B | 40 mm | Red | Mushroom head | Spring bolt key E100 |
| 800T-E1546M6A1 | 40 mm | Red | Mushroom head | Spring bolt key E100 |
| 800T-E1546M6 | 40 mm | Red | Mushroom head | Spring bolt key E100 |
| 800T-E1546B | N/A | N/A | Standard unit | Spring bolt key E100 |
| 800T-E1546A | N/A | N/A | Standard unit | Spring bolt key E100 |
| 800T-E1545 | N/A | N/A | Standard unit | Spring bolt key E131 |
| 800T-E1544B | N/A | N/A | Standard unit | Spring bolt key E109 |
| 800T-E1545A | N/A | N/A | Standard unit | Spring bolt key E131 |
| 800T-E1544M6D4 | 40 mm | Red | Mushroom head | Spring bolt key E109 |
Common to all listed parts
| Lifecycle | Discontinued |
| Discontinued date | April 30, 2025 |
| Replacement category (Rockwell) | No planned RA replacement |
| Repair options available | No |
| Enclosure compatibility (NEMA type) | 1, 4, 12, 13 |
| Hazardous location rating | false |
| Hole diameter | 30.5 mm |
| Humidity | 50 % |
