Kinetix MPL Low-inertia Servo Motors Parts
Compare Kinetix MPL Low-inertia Servo Motors
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Voltage | Frame Size | Magnet Stack Length | RPM | Enclosure |
|---|---|---|---|---|---|
| MPL-B4530K-RK74AA | (B) 460 V | (45) 130 mm (5.12 in.) | (30) 76.2 mm (3.0 in.) | (K) 4000 RPM | (K) Keyless Shaft Extension |
| MPL-B4530K-RJ72AA | (B) 460 V | (45) 130 mm (5.12 in.) | (30) 76.2 mm (3.0 in.) | (K) 4000 RPM | (J) Keyed Shaft Extension |
| MPL-B4530F-RJ72AA | (B) 460 V | (45) 130 mm (5.12 in.) | (30) 76.2 mm (3.0 in.) | (F) 3000 RPM | (J) Keyed Shaft Extension |
| MPL-B430P-RJ74AA | (B) 460 V | (4) 115 mm (4.53 in.) | (30) 76.2 mm (3.0 in.) | (P) 5000 RPM | (J) Keyed Shaft Extension |
| MPL-B430P-RJ72AA | (B) 460 V | (4) 115 mm (4.53 in.) | (30) 76.2 mm (3.0 in.) | (P) 5000 RPM | (J) Keyed Shaft Extension |
| MPL-B320P-RK72AA | (B) 460 V | (3) 100 mm (3.94 in.) | (20) 50.8 mm (2.0 in.) | (P) 5000 RPM | (K) Keyless Shaft Extension |
| MPL-B320P-RJ74AA | (B) 460 V | (3) 100 mm (3.94 in.) | (20) 50.8 mm (2.0 in.) | (P) 5000 RPM | (J) Keyed Shaft Extension |
| MPL-B320P-RJ72AA | (B) 460 V | (3) 100 mm (3.94 in.) | (20) 50.8 mm (2.0 in.) | (P) 5000 RPM | (J) Keyed Shaft Extension |
| MPL-B420P-RK72AA | (B) 460 V | (4) 115 mm (4.53 in.) | (20) 50.8 mm (2.0 in.) | (P) 5000 RPM | (K) Keyless Shaft Extension |
| MPL-B330P-RK72AA | (B) 460 V | (3) 100 mm (3.94 in.) | (30) 76.2 mm (3.0 in.) | (P) 5000 RPM | (K) Keyless Shaft Extension |
| MPL-B330P-RJ72AA | (B) 460 V | (3) 100 mm (3.94 in.) | (30) 76.2 mm (3.0 in.) | (P) 5000 RPM | (J) Keyed Shaft Extension |
| MPL-B430P-RK74AA | (B) 460 V | (4) 115 mm (4.53 in.) | (30) 76.2 mm (3.0 in.) | (P) 5000 RPM | (K) Keyless Shaft Extension |
| MPL-B4530K-RK72AA | (B) 460 V | (45) 130 mm (5.12 in.) | (30) 76.2 mm (3.0 in.) | (K) 4000 RPM | (K) Keyless Shaft Extension |
| MPL-B4540F-RK74AA | (B) 460 V | (45) 130 mm (5.12 in.) | (40) 101.6 mm (4.0 in.) | (F) 3000 RPM | (K) Keyless Shaft Extension |
| MPL-B420P-RJ74AA | (B) 460 V | (4) 115 mm (4.53 in.) | (20) 50.8 mm (2.0 in.) | (P) 5000 RPM | (J) Keyed Shaft Extension |
| MPL-B310P-RK74AA | (B) 460 V | (3) 100 mm (3.94 in.) | (10) 25.4 mm (1.0 in.) | (P) 5000 RPM | (K) Keyless Shaft Extension |
| MPL-B330P-RK74AA | (B) 460 V | (3) 100 mm (3.94 in.) | (30) 76.2 mm (3.0 in.) | (P) 5000 RPM | (K) Keyless Shaft Extension |
| MPL-B420P-RK74AA | (B) 460 V | (4) 115 mm (4.53 in.) | (20) 50.8 mm (2.0 in.) | (P) 5000 RPM | (K) Keyless Shaft Extension |
| MPL-B4540F-RJ72AA | (B) 460 V | (45) 130 mm (5.12 in.) | (40) 101.6 mm (4.0 in.) | (F) 3000 RPM | (J) Keyed Shaft Extension |
| MPL-B310P-RJ74AA | (B) 460 V | (3) 100 mm (3.94 in.) | (10) 25.4 mm (1.0 in.) | (P) 5000 RPM | (J) Keyed Shaft Extension |
| MPL-B330P-RJ74AA | (B) 460 V | (3) 100 mm (3.94 in.) | (30) 76.2 mm (3.0 in.) | (P) 5000 RPM | (J) Keyed Shaft Extension |
| MPL-B4530F-RK74AA | (B) 460 V | (45) 130 mm (5.12 in.) | (30) 76.2 mm (3.0 in.) | (F) 3000 RPM | (K) Keyless Shaft Extension |
| MPL-B310P-RJ72AA | (B) 460 V | (3) 100 mm (3.94 in.) | (10) 25.4 mm (1.0 in.) | (P) 5000 RPM | (J) Keyed Shaft Extension |
| MPL-A4530F-MK74AA | (A) 230 V | (45) 130 mm (5.12 in.) | (30) 76.2 mm (3.0 in.) | (F) 3000 RPM | (K) Keyless Shaft Extension |
Common to all listed parts
| Product Type | Bulletin MPL - Low-Inertia Brushless Servo Motors Product |
| Connectors | (7) SpeedTEC DIN Connector, Right Angle, 180° Rotatable (Quick Connect) |
