Altivar 212 Parts
Schneider Electric
ATV212WD55N4CVariable speed drive ATV212 - 55kW - 40hp - 480V - 3ph - EMC class C1 - IP55
Schneider Electric
ATV212WD55N4Variable speed drive ATV212 - 55kW - 75hp - 480V - 3ph - EMC class C2 - IP55
Schneider Electric
ATV212HU75M3XVariable speed drive ATV212 - 7.5kW - 10hp - 240V - 3ph - wo EMC - IP21
Schneider Electric
ATV212HU55M3XVariable speed drive ATV212 - 5.5kW - 7.5hp - 240V - 3ph - wo EMC - IP21
Schneider Electric
ATV212HU15M3XVariable speed drive ATV212 - 1.5kW - 1.5hp - 240V - 3ph - wo EMC - IP21
Schneider Electric
ATV212HU22M3XVariable speed drive ATV212 - 2.2kW - 3hp - 240V - 3ph - wo EMC - IP21
Compare Altivar 212
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Motor power kW | Line current | Apparent power | Continuous output current | Maximum transient current |
|---|---|---|---|---|---|
| ATV212WU75N4CZH28 | 7.5 kW | 11.7 A at 480 V; 14.7 A at 380 V | 12.2 kVA at 380 V | 16 A at 380 V; 16 A at 460 V | 17.6 A for 60 s |
| ATV212WU55N4CZH28 | 5.5 kW | 11 A at 380 V; 8.7 A at 480 V | 9.1 kVA at 380 V | 12 A at 380 V; 12 A at 460 V | 13.2 A for 60 s |
| ATV212WU40N4CZH28 | 4 kW | 6.5 A at 480 V; 8.2 A at 380 V | 6.9 kVA at 380 V | 9.1 A at 380 V; 9.1 A at 460 V | 10 A for 60 s |
| ATV212WU30N4CZH28 | 3 kW | 6.2 A at 380 V; 5 A at 480 V | 5.5 kVA at 380 V | 7.2 A at 380 V; 7.2 A at 460 V | 7.9 A for 60 s |
| ATV212WU22N4CZH28 | 2.2 kW | 4.6 A at 380 V; 3.7 A at 480 V | 3.9 kVA at 380 V | 5.1 A at 380 V; 5.1 A at 460 V | 5.6 A for 60 s |
| ATV212WU15N4CZH28 | 1.5 kW | 3.2 A at 380 V; 2.6 A at 480 V | 2.8 kVA at 380 V | 3.7 A at 380 V; 3.7 A at 460 V | 4 A for 60 s |
| ATV212WD75N4CZH28 | 75 kW | 141.8 A at 380 V; 111.3 A at 480 V | 105.3 kVA at 380 V | 160 A at 380 V; 160 A at 460 V | 176 A for 60 s |
| ATV212WD55N4CZH28 | 55 kW | 102.7 A at 380 V; 89 A at 480 V | 76.3 kVA at 380 V | 116 A at 380 V; 116 A at 460 V | 127.6 A for 60 s |
| ATV212WD55N4C | 55 kW | 102.7 A at 380 V; 89 A at 480 V | 76.3 kVA at 380 V | 116 A at 380 V; 116 A at 460 V | 127.6 A for 60 s |
| ATV212WD55N4 | 55 kW | 102.7 A at 380 V; 89 A at 480 V | 76.3 kVA at 380 V | 116 A at 380 V; 116 A at 460 V | 127.6 A for 60 s |
| ATV212WD45N4CZH28 | 45 kW | 83.8 A at 380 V; 65.9 A at 480 V | 61.9 kVA at 380 V | 94 A at 380 V; 94 A at 460 V | 103.4 A for 60 s |
| ATV212WD37N4CZH28 | 37 kW | 68.9 A at 380 V; 54.4 A at 480 V | 52 kVA at 380 V | 79 A at 380 V; 79 A at 460 V | 86.9 A for 60 s |
| ATV212WD18N4CZH28 | 18.5 kW | 27.6 A at 480 V; 34.5 A at 380 V | 23.2 kVA at 380 V | 37 A at 380 V; 37 A at 460 V | 40.7 A for 60 s |
| ATV212WD30N4CZH28 | 30 kW | 44.4 A at 480 V; 58.2 A at 380 V | 44.6 kVA at 380 V | 58.5 A at 380 V; 58.5 A at 460 V | 64.4 A for 60 s |
| ATV212WD22N4CZH28 | 22 kW | 33.1 A at 480 V; 41.1 A at 380 V | 33.2 kVA at 380 V | 43.5 A at 380 V; 43.5 A at 460 V | 47.9 A for 60 s |
| ATV212WD15N4CZH28 | 15 kW | 22.8 A at 480 V; 28.4 A at 380 V | 23.2 kVA at 380 V | 30.5 A at 380 V; 30.5 A at 460 V | 33.6 A for 60 s |
| ATV212W075N4CZH28 | 0.75 kW | 1.4 A at 480 V; 1.7 A at 380 V | 1.6 kVA at 380 V | 2.2 A at 380 V; 2.2 A at 460 V | 2.4 A for 60 s |
| ATV212WD11N4CZH28 | 11 kW | 21.1 A at 380 V; 16.7 A at 480 V | 17.1 kVA at 380 V | 22.5 A at 380 V; 22.5 A at 460 V | 24.8 A for 60 s |
| ATV212HU75M3X | 7.5 kW | 23.3 A at 240 V; 27.9 A at 200 V | 12.2 kVA at 240 V | 32 A at 230 V | 35.2 A for 60 s |
| ATV212HU55M3X | 5.5 kW | 17.3 A at 240 V; 20.8 A at 200 V | 9.2 kVA at 240 V | 24.2 A at 230 V | 26.6 A for 60 s |
| ATV212HU40M3X | 4 kW | 13 A at 240 V; 15.7 A at 200 V | 6.7 kVA at 240 V | 17.5 A at 230 V | 19.3 A for 60 s |
| ATV212HU30M3X | 3 kW | 10 A at 240 V; 11.9 A at 200 V | 5.2 kVA at 240 V | 13.7 A at 230 V | 15.1 A for 60 s |
| ATV212HU15M3X | 1.5 kW | 5.1 A at 240 V; 6.1 A at 200 V | 2.9 kVA at 240 V | 7.5 A at 230 V | 8.3 A for 60 s |
| ATV212HU22M3X | 2.2 kW | 7.3 A at 240 V; 8.7 A at 200 V | 4 kVA at 240 V | 10.6 A at 230 V | 11.7 A for 60 s |
Common to all listed parts
| Device short name | ATV212 |
| Product destination | Asynchronous motors |
| Network number of phases | 3 phases |
| Supply frequency | 50...60 Hz - 5...5 % |
| Range of product | Altivar 212 |
| Product or component type | Variable speed drive |
| Product specific application | Pumps and fans in HVAC |
| Speed drive output frequency | 0.5…200 Hz |
