Altivar 31 Parts

Schneider Electric

ATV31KU75N4T

Variable speed drive ATV31 - 7.5 kW - 380..500 V - 3 phases supply- wire guiding

Schneider Electric

ATV31KU75N4

Variable speed drive ATV31 - 7.5 kW - 380..500 V - 3 phases supply

Schneider Electric

ATV31KU55N4T

Variable speed drive ATV31 - 5.5 kW - 380..500 V - 3 phases supply- wire guiding

Schneider Electric

ATV31KU55N4

Variable speed drive ATV31 - 5.5 kW - 380..500 V - 3 phases supply

Schneider Electric

ATV31KU40N4T

Variable speed drive ATV31 - 4 kW - 380..500 V - 3 phases supply- wire guiding

Schneider Electric

ATV31KU40N4

Variable speed drive ATV31 - 4 kW - 380..500 V - 3 phases supply

Schneider Electric

ATV31KU30N4T

Variable speed drive ATV31 - 3 kW - - 380..500 V - 3 phases supply- wire guiding

Schneider Electric

ATV31KU22N4T

Variable speed drive ATV31 - 2.2 kW - 380..500 V - 3 phases supply- wire guiding

Schneider Electric

ATV31KU30N4

Variable speed drive ATV31 - 3 kW - - 380..500 V - 3 phases supply

Schneider Electric

ATV31KU22N4

Variable speed drive ATV31 - 2.2 kW - 380..500 V - 3 phases supply

Schneider Electric

ATV31KU22M2T

Variable speed drive ATV31 - 2.2 kW - 200..240 V - 1 phase supply- wire guiding

Schneider Electric

ATV31KU22M2

Variable speed drive ATV31 - 2.2 kW - 200..240 V - 1 phase supply

Schneider Electric

ATV31KU15N4T

Variable speed drive ATV31 - 1.5 kW - 380..500 V - 3 phases supply- wire guiding

Schneider Electric

ATV31KU15N4

Variable speed drive ATV31 - 1.5 kW - 380..500 V - 3 phases supply

Schneider Electric

ATV31KU15M2T

Variable speed drive ATV31 - 1.5 kW - 200..240 V - 1 phase supply- wire guiding

Schneider Electric

ATV31KU15M2

Variable speed drive ATV31 - 1.5 kW - 200..240 V - 1 phase supply

Schneider Electric

ATV31KU11N4T

Variable speed drive ATV31 - 1.1 kW - 380..500 V - 3 phases supply- wire guiding

Schneider Electric

ATV31KU11N4

Variable speed drive ATV31 - 1.1 kW - 380..500 V - 3 phases supply

Schneider Electric

ATV31KU11M2T

Variable speed drive ATV31 - 1.1 kW - 200..240 V - 1 phase supply- wire guiding

Schneider Electric

ATV31KU11M2

Variable speed drive ATV31 - 1.1 kW - 200..240 V - 1 phase supply

Schneider Electric

ATV31KD15N4T

Variable speed drive ATV31 - 15 kW - 380..500 V - 3 phases supply- wire guiding

Schneider Electric

ATV31KD15N4

Variable speed drive ATV31 - 15 kW - 380..500 V - 3 phases supply

Schneider Electric

ATV31KD11N4T

Variable speed drive ATV31 - 11 kW - 380..500 V - 3 phases supply- wire guiding

Schneider Electric

ATV31KD11N4

Variable speed drive ATV31 - 11 kW - 380..500 V - 3 phases supply

Compare Altivar 31

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPN	Line current	Nominal output current	Maximum transient current	Power dissipation in W	Product certifications
ATV31KU75N4T	21 A at 500 V; 27.7 A at 380 V	17 A 4 kHz	25.5 A for 60 s	269 W at nominal load	N998; CSA; UL; C-Tick
ATV31KU75N4	21 A at 500 V; 27.7 A at 380 V	17 A 4 kHz	25.5 A for 60 s	269 W at nominal load	N998; C-Tick; CSA; UL
ATV31KU55N4T	16.5 A at 500 V; 21.9 A at 380 V	14.3 A 4 kHz	21.5 A for 60 s	232 W at nominal load	N998; CSA; UL; C-Tick
ATV31KU55N4	16.5 A at 500 V; 21.9 A at 380 V	14.3 A 4 kHz	21.5 A for 60 s	232 W at nominal load	N998; CSA; C-Tick; UL
ATV31KU40N4T	10.6 A at 500 V; 13.9 A at 380 V	9.5 A 4 kHz	14.3 A for 60 s	150 W at nominal load	N998; UL; C-Tick; CSA
ATV31KU40N4	10.6 A at 500 V; 13.9 A at 380 V	9.5 A 4 kHz	14.3 A for 60 s	150 W at nominal load	UL; N998; CSA; C-Tick
ATV31KU30N4T	10.9 A at 380 V; 8.3 A at 500 V	7.1 A 4 kHz	10.7 A for 60 s	125 W at nominal load	N998; UL; C-Tick; CSA
ATV31KU22N4T	6.7 A at 500 V; 8.9 A at 380 V	5.5 A 4 kHz	8.3 A for 60 s	79 W at nominal load	CSA; UL; C-Tick; N998
ATV31KU30N4	10.9 A at 380 V; 8.3 A at 500 V	7.1 A 4 kHz	10.7 A for 60 s	125 W at nominal load	UL; N998; C-Tick; CSA
ATV31KU22N4	6.7 A at 500 V; 8.9 A at 380 V	5.5 A 4 kHz	8.3 A for 60 s	79 W at nominal load	CSA; N998; UL; C-Tick
ATV31KU22M2T	18.4 A at 240 V; 21.9 A at 200 V	11 A 4 kHz	16.5 A for 60 s	123 W at nominal load	N998; C-Tick; UL; CSA
ATV31KU22M2	18.4 A at 240 V; 21.9 A at 200 V	11 A 4 kHz	16.5 A for 60 s	123 W at nominal load	UL; CSA; C-Tick; N998
ATV31KU15N4T	4.8 A at 500 V; 6.4 A at 380 V	4.1 A 4 kHz	6.2 A for 60 s	61 W at nominal load	CSA; C-Tick; N998; UL
ATV31KU15N4	4.8 A at 500 V; 6.4 A at 380 V	4.1 A 4 kHz	6.2 A for 60 s	61 W at nominal load	C-Tick; UL; CSA; N998
ATV31KU15M2T	13.3 A at 240 V; 15.8 A at 200 V	8 A 4 kHz	12 A for 60 s	90 W at nominal load	N998; UL; CSA; C-Tick
ATV31KU15M2	13.3 A at 240 V; 15.8 A at 200 V	8 A 4 kHz	12 A for 60 s	90 W at nominal load	C-Tick; UL; CSA; N998
ATV31KU11N4T	3.7 A at 500 V; 4.9 A at 380 V	3 A 4 kHz	4.5 A for 60 s	48 W at nominal load	N998; UL; CSA; C-Tick
ATV31KU11N4	3.7 A at 500 V; 4.9 A at 380 V	3 A 4 kHz	4.5 A for 60 s	48 W at nominal load	UL; N998; CSA; C-Tick
ATV31KU11M2T	10.2 A at 240 V; 12.1 A at 200 V	6.9 A 4 kHz	10.4 A for 60 s	74 W at nominal load	UL; N998; C-Tick; CSA
ATV31KU11M2	10.2 A at 240 V; 12.1 A at 200 V	6.9 A 4 kHz	10.4 A for 60 s	74 W at nominal load	CSA; C-Tick; N998; UL
ATV31KD15N4T	36.8 A at 500 V; 48.2 A at 380 V	33 A 4 kHz	49.5 A for 60 s	492 W at nominal load	UL; N998; C-Tick; CSA
ATV31KD15N4	36.8 A at 500 V; 48.2 A at 380 V	33 A 4 kHz	49.5 A for 60 s	492 W at nominal load	N998; UL; C-Tick; CSA
ATV31KD11N4T	28.4 A at 500 V; 37.2 A at 380 V	27.7 A 4 kHz	41.6 A for 60 s	397 W at nominal load	N998; C-Tick; CSA; UL
ATV31KD11N4	28.4 A at 500 V; 37.2 A at 380 V	27.7 A 4 kHz	41.6 A for 60 s	397 W at nominal load	C-Tick; CSA; UL; N998

Common to all listed parts

Range of product	Altivar
Product or component type	Variable speed drive
Component name	ATV31
Assembly style	Kit
EMC filter	Integrated
Asynchronous motor control profile	Sensorless flux vector control with PWM type motor control signal
Analogue input number	3
Product destination	Asynchronous motors
