ACS550 Parts
Compare ACS550
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Product Net Weight | Output Current, Normal Use (In) | Output Current, Heavy-Duty Use (IHD) | Output Power, Normal Use (Pn) | Output Power, Heavy-Duty Use (PHD) |
|---|---|---|---|---|---|
| ACS550-01-031A-4 | 18 kg kg | 31 A A | 23 A A | 15 kW kW | 11 kW kW |
| ACS550-01-015A-4 | 9 kg kg | 15.4 A A | 11.9 A A | 7.5 kW kW | 5.5 kW kW |
| ACS550-01-08A8-4 | 6.1 kg kg | 8.8 A A | 6.9 A A | 4 kW kW | 3 kW kW |
| ACS800-07-0610-3 | 890 kg kg | 879 A A | 657 A A | 500 kW kW | 400 kW kW |
| ACS550-01-06A9-4 | 6.1 kg kg | 6.9 A A | 5.4 A A | 3 kW kW | 2.2 kW kW |
| ACH550-02-526A-4 | 248 kg kg | 526 A A | — | 280 kW kW | — |
| ACS800-07-0260-5 | 400 kg kg | 289 A A | 224 A A | 200 kW kW | 160 kW kW |
| ACS550-01-157A-4 | 78 kg kg | 157 A A | 125 A A | 75 kW kW | 55 kW kW |
| ACSM1-04LM-135A-4 | — | — | — | — | — |
| ACS800-07-0870-7 | 1100 kg kg | 729 A A | 545 A A | 710 kW kW | 560 kW kW |
| ACS550-01-180A-4 | 78 kg kg | 180 A A | 156 A A | 90 kW kW | 75 kW kW |
| ACSM1-04LS-210A-4 | — | — | — | — | — |
| ACH550-01-044A-4+B055 | 25.8 kg kg | 44 A A | — | 22 kW kW | — |
| ACS800-07-2900-7 | 2280 kg kg | 2321 A A | 1736 A A | 2300 kW kW | 1600 kW kW |
| ACS800-07-1210-5 | 1200 kg kg | 1372 A A | 1026 A A | 1000 kW kW | 710 kW kW |
| ACS800-07-0770-3 | 1200 kg kg | 1111 A A | 831 A A | 630 kW kW | 450 kW kW |
| ACS800-07-0170-5 | 400 kg kg | 196 A A | 162 A A | 132 kW kW | 110 kW kW |
| ACH550-02-368A-4 | 234 kg kg | 368 A A | — | 200 kW kW | — |
| ACS800-U7-0140-7 | 400 kg kg | 125 A A | 95 A A | 125 Hp | 100 Hp |
| ACS800-U7-0260-5 | 400 kg kg | 289 A A | 224 A A | 250 Hp | 150 Hp |
| ACS800-07-1090-5 | 1200 kg kg | 1258 A A | 941 A A | 900 kW kW | 630 kW kW |
| ACS800-07-2310-5 | 2130 kg kg | 2670 A A | 1997 A A | 1900 kW kW | 1400 kW kW |
| ACS800-07-0070-3 | 300 kg kg | 141 A A | 97 A A | 75 kW kW | 45 kW kW |
| ACS550-01-05A4-4 | 6.17 kg kg | 5.4 A A | 4.1 A A | 2.2 kW kW | 1.5 kW kW |
Common to all listed parts
| Minimum Order Quantity | 1 piece |
| Order Multiple | 1 piece |
| Quote Only | No |
| Selling Unit of Measure | piece |
| Number of Phases | 3-phase |
