Compare Antennas ID 200
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Transmission frequency | Write/read distance, static [mm] | Write/read distance, dynamic [mm] | Min. distance between 2 antennas multiplex [mm] | Min. distance between 2 antennas simultaneously [mm] |
|---|
| 3842410177 | 125 | 15 | 12 | 30 | 180 |
| 3842410176 | 125 | 15 | 12 | 50 | 290 |
| 3842410063 | 13.56 | 35 | 30 | 30 | 80 |
| 3842410065 | 13.56 | 35 | 30 | 100 | 150 |
Common to all listed parts
| Mass [m] [kg] | 0.1 |
| Protection class | IP67 |
| Ambient temperature [T] | -25 … +70 °C |
| Operating voltage DC [V] | 24 |
| Storage temperature [T] | -40 … +85 °C |
| Status indicator 01 | LED orange/green |
| Shock and impact resistance (EN 60068-2-29) | 30 g/11 ms 18 cycles |
| Dynamic data transfer | No |
