Linear sets with linear bushings Parts
Compare Linear sets with linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Dynamic load capacity C [N] | Outer diameter D [mm] | Weight [kg] | Static load capacity C0 [N] |
|---|---|---|---|---|---|
| R106881640 | 16.0 | 1280.0 | 26.0 | 0.23 | 630.0 |
| R106881240 | 12.0 | 1060.0 | 22.0 | 0.14 | 510.0 |
| R106861640 | 16.0 | 1280.0 | 26.0 | 0.23 | 630.0 |
| R106861240 | 12.0 | 1060.0 | 22.0 | 0.13 | 510.0 |
| R106781640 | 16.0 | 1280.0 | 26.0 | 0.22 | 630.0 |
| R106781240 | 12.0 | 1060.0 | 22.0 | 0.14 | 510.0 |
| R106761640 | 16.0 | 1280.0 | 26.0 | 0.23 | 630.0 |
| R106761240 | 12.0 | 1060.0 | 22.0 | 0.13 | 510.0 |
| R109755079 | 50.0 | 15000.0 | 75.0 | 0 | 12940.0 |
| R109755089 | 50.0 | 15000.0 | 75.0 | 0 | 12940.0 |
| R109755085 | 50.0 | 15000.0 | 75.0 | 0.1 | 12940.0 |
| R109755080 | 50.0 | 15000.0 | 75.0 | 0.1 | 12940.0 |
| R109755088 | 50.0 | 15000.0 | 75.0 | 0.1 | 12940.0 |
| R109755087 | 50.0 | 15000.0 | 75.0 | 34 | 12940.0 |
| R109755069 | 50.0 | 15000.0 | 75.0 | 0 | 12940.0 |
| R109755086 | 50.0 | 15000.0 | 75.0 | 0 | 12940.0 |
| R109754079 | 40.0 | 10200.0 | 62.0 | 0 | 8700.0 |
| R109754089 | 40.0 | 10200.0 | 62.0 | 0 | 8700.0 |
| R109754085 | 40.0 | 10200.0 | 62.0 | 0.1 | 8700.0 |
| R109754080 | 40.0 | 10200.0 | 62.0 | 0.86 | 8700.0 |
| R109754088 | 40.0 | 10200.0 | 62.0 | 0.1 | 8700.0 |
| R109754087 | 40.0 | 10200.0 | 62.0 | 22 | 8700.0 |
| R109754069 | 40.0 | 10200.0 | 62.0 | 0 | 8700.0 |
| R109754086 | 40.0 | 10200.0 | 62.0 | 0 | 8700.0 |
Common to all listed parts
| Type | Linear set |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
