Compare PSENrope
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Product ID (Pilz order number) | Ambient temperature | Net weight | Gross weight | GTIN |
|---|
| 570301 | 570301 | -30 … 80 °C | 933 g | 1052 g | 4046548062717 |
| 570303 | 570303 | -25 … 70 °C | 680 g | 775 g | 4046548062823 |
| 570300 | 570300 | -30 … 80 °C | 939 g | 1056 g | 4046548062816 |
| 570302 | 570302 | -25 … 70 °C | 680 g | 775 g | 4046548062724 |
Common to all listed parts
| Approval | CE, UKCA, BG, cCSAus, EAC (Eurasian) |
| Lifecycle | Active (current Pilz product) |
| Utilisation cat. AC15/DC13sta. | EN 60947-5-1 |
| Voltage AC15 safety cont. | 240 |
| Max. current AC15 safety cont. | 3 |
| Protection type, housing | IP67 |
| Material actuator | Zn die cast |
| RoHS directive | 2011/65/EU, 2015/863/EU |
