Home / Sensor technology / Safety switches with guard locking / PSENslock - safety locking devices / PSENslock

PSENslock Parts

Pilz

570665

PSEN sl-1.0n 2.2 / PSEN sl-1.0fm 1unit

Pilz

570664

PSEN sl-1.0n 2.1 / PSEN sl-1.0fm 1unit

Pilz

570663

PSEN sl-1.0n 1.1 / PSEN sl-1.0fm 1unit

Pilz

570614

PSEN sl-1.0n 2.1 1switch

Pilz

570613

PSEN sl-1.0n 1.1 1switch

Pilz

570605

PSEN sl-1.0n 2.2 / PSEN sl-1.0 1unit

Pilz

570604

PSEN sl-1.0n 2.1 / PSEN sl-1.0 1unit

Pilz

570603

PSEN sl-1.0n 1.1 / PSEN sl-1.0 1unit

Pilz

570565

PSEN sl-0.5n 2.2 / PSEN sl-0.5fm 1unit

Pilz

570564

PSEN sl-0.5n 2.1 / PSEN sl-0.5fm 1unit

Pilz

570563

PSEN sl-0.5n 1.1 / PSEN sl-0.5fm 1unit

Pilz

570514

PSEN sl-0.5n 2.1 1switch

Pilz

570513

PSEN sl-0.5n 1.1 1switch

Pilz

570505

PSEN sl-0.5n 2.2 / PSEN sl-0.5 1unit

Pilz

570504

PSEN sl-0.5n 2.1 / PSEN sl-0.5 1unit

Pilz

570503

PSEN sl-0.5n 1.1 / PSEN sl-0.5 1unit

Pilz

570640

PSEN sl-1.0p 1.1 VA 1switch

Pilz

570620

PSEN sl-1.0 1.1 1actuator

Pilz

570581

PSEN sl-0.5p 6.1/PSEN sl-0.5 1unit

Pilz

570588

PSEN sl-0.5p 6.1

Pilz

570584

PSEN sl-0.5p 6.1/PSEN sl-0.5fm 1unit

Pilz

570684

PSEN sl-1.0p 6.1/PSEN sl-1.0fm 1unit

Pilz

570681

PSEN sl-1.0p 6.1/PSEN sl-1.0 1unit

Pilz

570688

PSEN sl-1.0p 6.1

Compare PSENslock

Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.

MPN	Product ID (Pilz order number)	Type 1 actuator	Net weight	Gross weight	GTIN
570665	570665	PSEN sl-1.0fm 2.1	1710 g	1770 g	4046548080933
570664	570664	PSEN sl-1.0fm 2.1	1710 g	1770 g	4046548080926
570663	570663	PSEN sl-1.0fm 1.1	1710 g	1770 g	4046548080919
570614	570614	PSEN sl-1.0 2.1	1120 g	1190 g	4046548063752
570613	570613	PSEN sl-1.0 1.1	1120 g	1190 g	4046548063745
570605	570605	PSEN sl-1.0 2.1	1720 g	1780 g	4046548063738
570604	570604	PSEN sl-1.0 2.1	1720 g	1780 g	4046548063721
570603	570603	PSEN sl-1.0 1.1	1720 g	1780 g	4046548063714
570565	570565	PSEN sl-0.5fm 2.1	940 g	980 g	4046548080902
570564	570564	PSEN sl-0.5fm 2.1	940 g	980 g	4046548080896
570563	570563	PSEN sl-0.5fm 1.1	940 g	980 g	4046548080889
570514	570514	PSEN sl-0.5 2.1	570 g	630 g	4046548063707
570513	570513	PSEN sl-0.5 1.1	570 g	630 g	4046548063691
570505	570505	PSEN sl-0.5 2.1	950 g	990 g	4046548063684
570504	570504	PSEN sl-0.5 2.1	950 g	990 g	4046548063677
570503	570503	PSEN sl-0.5 1.1	950 g	990 g	4046548063660
570640	570640	PSEN sl-1.0 VA	1470 g	1540 g	4046548064254
570620	570620	—	600 g	680 g	4046548061352
570581	570581	PSEN sl-0.5 2.1	950 g	990 g	4046548081503
570588	570588	PSEN sl-0.5 2.1	570 g	630 g	4046548081633
570584	570584	PSEN sl-0.5fm 2.1	940 g	980 g	4046548081534
570684	570684	PSEN sl-1.0fm 2.1	1710 g	1770 g	4046548081602
570681	570681	PSEN sl-1.0 2.1	1720 g	1780 g	4046548081565
570688	570688	PSEN sl-1.0 2.1	1120 g	1190 g	4046548081664

Common to all listed parts

Approval	CE, UKCA, cULus Listed, FCC, IC, EAC (Eurasian)
Sensor principle	Transponder
Lifecycle	Discontinued (no longer manufactured by Pilz)
Ambient temperature standard	EN 60068-2-14
Ambient temperature	-25 … 55 °C
Storage temperature standard	EN 60068-2-1/-2
Climatic suitability standard	EN 60068-2-78
Humidity rating	93 % r. h. at 40 °C
