B&R 1TGMPAUDIT.10-01 – mapp Audit collects and manages a wide range of different…
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Technology Guard |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 1TGMPAUDIT.10-01 be shipped?
1TGMPAUDIT.10-01 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 1TGMPAUDIT.10-01 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 1TGMPAUDIT.10-01 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1TGMPAUDIT.10-01, subject to availability and destination.
mapp Audit collects and manages a wide range of different events. These include when user-defined events occur, when machine operators log in/out or when an alarm occurs. All events are collected and can be exported with password protection to protect them from tampering. Functional scope:
mapp Audit defines which types of events on a machine should be recorded. These can include OPC UA events, value changes, user-defined events, alarm management events (mapp AlarmX), user management events (mapp UserX) or other mapp components. The collected events can be displayed in an HMI application and exported to a storage medium as a text or PDF file. The event list can be filtered with a filter function. The created audit trail is tamper-resistant and password-protected to ensure data integrity.
Accessories
Required accessories (order separately)
| 1TGMPSRV.00-01 | Technology Guard — Creating alarm, user and recipe management; Visual display of alarm, user and recipe management; Modifying the hardware configuration at ru… |
Optional accessories (7)
| X20CMR111 | Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po… |
| X20CMR100 | Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po… |
| X20CMR011 | Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po… |
| X20cCMR011 | Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po… |
| 0TGF016.01 | Technology Guard — Technology Guard (MSD) with integrated flash drive, 16 GB (MLC) |
| 0TG1000.02 | Technology Guard — Technology Guard (HID) |
| 0TG1000.01 | Technology Guard — Technology Guard (MSD) |
Specifications
General information
| System requirements – Automation Studio | 4.3.3 or later |
| System requirements – Automation Runtime | B4.34 or later |
| System requirements – mapp Technology Package | mapp Services |
| Certifications – CRA (Cyber Resilience Act) | In preparation |
| Basic package license | 1TGMPSRV.00-01 |
| Behavior if license missing | License violation indicated by red blinking LED |
Downloads & documentation
Official documents from B&R, downloaded directly from the manufacturer.
Certificates (1)
| EULA (End User License Agreement) - AS, AR & mapp Technology | PDF · 317 KB · 1.20 (08/12/2025) - EN |
