B&R 1TGMPAUDIT.02 – mapp Technology, 1TGMPAUDIT.02 B&R software license
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Technology Guard |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 1TGMPAUDIT.02 be shipped?
1TGMPAUDIT.02 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 1TGMPAUDIT.02 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 1TGMPAUDIT.02 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1TGMPAUDIT.02, subject to availability and destination.
• Configuring event types
• Creating entries
• Configuration during runtime
• OPC UA events
• VC4 event system under MpAudit
MpAudit can be used to log various events. These events could come from the HMI application, MpUser or from user-defined events. The user can determine the format in which the events are stored in a file.
MpAudit provides many functions that make it easier to implement 21 CFR Part 11 requirements (e.g. logging unauthorized access attempts).
Accessories
Required accessories (order separately)
| 0TG1000.02 | Technology Guard — Technology Guard (HID) |
| 0TG1000.01 | Technology Guard — Technology Guard (MSD) |
Specifications
Specifications
| mapp Technology | 1TGMPAUDIT.02 B&R software license |
| Automation Studio | 4.2.5 or later |
| Automation Runtime | F4.25 or later |
| Single-user license | Runtime license |
| Alternative package license | mapp flat-rate 1TGMPFLAT.02 |
| Behavior if license missing | Solid red LED indicates license violation |
| Diagnostics | Via Automation Studio (SDM, Logger, etc.) |
| CRA (Cyber Resilience Act) | Evaluation ongoing |
| Included library | MpAudit |
| Tracing variable values | No |
| Dynamic variable assignment | No |
| Recordings | Yes, various configurable events (user management, alarm management, OPC UA, etc.) |
| Data archival | Yes, wide range of formats possible (encrypted as ZIP archive, readable PDF, etc.) |
| Modular software concepts | Supported |
| Web-based diagnostics | Yes |
| XML configuration | Yes |
| Use cases | - Auditing without HMI - Auditing with local VC4-based HMI application - Logging of OPC UA variables |
Downloads & documentation
Official documents from B&R, downloaded directly from the manufacturer.
Data sheets & manuals
| Data sheet MpAudit | PDF · 6 MB · 1.00 (03/10/2017) - EN |
