B&R 1TGMPENERGY.10-01 – mapp Energy collects energy data from various modules in…
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Technology Guard |
| Lifecycle | Active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 1TGMPENERGY.10-01 be shipped?
1TGMPENERGY.10-01 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 1TGMPENERGY.10-01 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 1TGMPENERGY.10-01 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1TGMPENERGY.10-01, subject to availability and destination.
mapp Energy collects energy data from various modules in the machine and prepares the data so that energy consumption can be visualized. In addition, data is collected and made available as a file for analysis. Typical applications:
• Calculating energy consumption and associated costs
• Recording energy data from individual machine components to optimize energy consumption
Functional scope:
When setting up mapp Energy, the user defines which modules are included in the calculation of the energy consumption. It is possible to differentiate between energy data and power data. This is not just possible for B&R components, but also components from 3rd-party manufacturers. The calculated data can either be included directly as part of the total energy consumption or simply saved and evaluated to monitor a certain machine component for later analysis. The collected data can be displayed in the HMI application as a table or graph. The information can be exported to a data storage device such as a USB flash drive.
Accessories
Required accessories (order separately)
| 1TGMPSRV.00-01 | Technology Guard — Creating alarm, user and recipe management; Visual display of alarm, user and recipe management; Modifying the hardware configuration at ru… |
Optional accessories (7)
| X20CMR111 | Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po… |
| X20CMR100 | Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po… |
| X20CMR011 | Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po… |
| X20cCMR011 | Other functions — Measurement and evaluation of the ambient conditions in the control cabinet; Recording ambient conditions; Recording operating hours and po… |
| 0TGF016.01 | Technology Guard — Technology Guard (MSD) with integrated flash drive, 16 GB (MLC) |
| 0TG1000.02 | Technology Guard — Technology Guard (HID) |
| 0TG1000.01 | Technology Guard — Technology Guard (MSD) |
Specifications
General information
| System requirements – Automation Studio | 4.3.3 or later |
| System requirements – Automation Runtime | B4.34 or later |
| System requirements – mapp Technology Package | mapp Services |
| Certifications – CRA (Cyber Resilience Act) | In preparation |
| Basic package license | 1TGMPSRV.00-01 |
| Behavior if license missing | License violation indicated by red blinking LED |
Downloads & documentation
Official documents from B&R, downloaded directly from the manufacturer.
Certificates (1)
| EULA (End User License Agreement) - AS, AR & mapp Technology | PDF · 317 KB · 1.20 (08/12/2025) - EN |
