B&R 8B0P0440HC00.001-1

Name: B&R 8B0P0440HC00.001-1
Brand: B&R
SKU: 8B0P0440HC00.001-1

MPN: 8B0P0440HC00.001-1 · Brand: B&R

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Cold plate or feed-through mounting
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can 8B0P0440HC00.001-1 be shipped?

8B0P0440HC00.001-1 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 8B0P0440HC00.001-1 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 8B0P0440HC00.001-1 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 8B0P0440HC00.001-1, subject to availability and destination.

Wide input voltage rangeIntegrated connection for external braking resistorPassive motor short circuit brake ACOPOSmulti power supply module passive, 44 A, AS, cold plate or pass-through mounting, passive motor short circuit brake

Specifications

Note	Integrated passive motor short circuit brake
B&R ID code	0xA98A
Dynamic node allocation (DNA)	Yes
Cooling and mounting type	Cold plate or pass-through mounting
CE	Yes
UKCA	Yes
CRA (Cyber Resilience Act)	In preparation
UL	cULus E225616 Power conversion equipment
KC	Yes
Network configurations	TT, TN-S, TN-C-S
Mains input voltage	3x 380 to 3x 500 VAC ±10%
Frequency	50 / 60 Hz ±4%
Installed load	Max. 30.4 kVA
Power dissipation with continuous power	In preparation
Inrush current at 400 VAC	10 A
Switch-on interval	>120 s
400 VAC	14.4 mF
480 VAC	10 mF
Integrated line filter per EN 61800-3, category C3	No
Integrated regeneration choke	No
Regenerative	No
Power factor correction (PFC)	No
Line fuse	Max. 132 A (gG fuses per IEC 60269-1 or Class CC, J, T) Max. 110 A (circuit breaker per EN 60947-2 or UL 489)
L1, L2, L3, PE	Connector
PE	M5 threaded bolt
Shield connection	Yes
With wire end sleeve	0.5 to 6 mm²
UL/C-UL-US	20 to 6 AWG
CSA	20 to 6 AWG
Terminal cable cross section dimension of shield connection	23 to 35 mm
Nominal	5 to 40°C
Continuous power	3 kW
Mains input voltage <3x 400 VAC	40 W/V * (400 V - Mains input voltage)
Starting at 500 m above sea level	1.6 kW per 1000 m
Reduction of continuous power depending on cooling method	In preparation
Peak power output (supply)	48 kW
DC bus capacitance	1320 µF
Overload protection	Yes
Short-circuit and ground fault protection	Yes (with RB+ by externally replaceable melting fuse)
Variant	ACOPOSmulti backplane
Input voltage	25 VDC ±1.6%
Input capacitance	23.5 µF
Max. power consumption	12 W
Peak power output	65 kW (max. 1 s)
Min. braking resistance	7.5 Ω
Rated current of built-in fuse	30 A (fast-acting)
RB+, RB-, PE	Connector
Discharge capacitance	0.9 µF
Power dissipation relative to continuous apparent power	IE2 (10;25) 0.1% IE2 (50;25) 0.1% IE2 (10;50) 0.1% IE2 (50;50) 0.2% IE2 (90;50) 0.5% IE2 (10;100) 0.1% IE2 (50;100) 0.5% IE2 (90;100) 1.2%
Nominal losses in standby mode	6 W
Hanging vertically	Yes
Horizontal, face up	Yes
Standing horizontally	No
Maximum	55°C
Pollution degree per EN 61800-5-1	2 (non-conductive pollution)
Overvoltage category per EN 61800-5-1	III
Degree of protection per EN 60529	IP20
Storage	5 to 95%
Transport	Max. 95% at 40°C
Operation	5 to 85%
Width	106.5 mm
Height	317 mm
Cold plate	212 mm
Pass-through mounting	209 mm
Weight	Approx. 4.9 kg
Module width	2
