BEARING LAL-A-G 15 BG

Name: BEARING LAL-A-G 15 BG
Brand: Bosch Rexroth
SKU: R159041500

MPN: R159041500 · Brand: Bosch Rexroth

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Accessories for ball screw assemblies
Lifecycle	active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can R159041500 be shipped?

R159041500 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up R159041500 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for R159041500 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for R159041500, subject to availability and destination.

The fixed bearing consists of: Angular-contact thrust ball bearing LGL, slotted nut NMG, NMZ. Suitable for screw end type 81, 81A, 82, 82A, 831/83, 83A, 841/84, 84A Double-thrust, screw-down, for inexpensive designs The fixed bearing consists of: Angular-contact thrust ball bearing LGL Slotted nuts NMG, NMZ Suitable for screw end form 81, 81A, 82, 82A, 831/83, 83A, 841/84, 84A

Specifications

Nominal size [mm]	25 x 5/10
Type	Angular-contact thrust ball bearing
Dynamic load capacity C [N]	16400.0
Note: dynamic load capacity C	Load on bearing (see general technical notes and information for bearings, "Project planning notes")
Outer diameter D [mm]	38.45
Weight [kg]	0.17
Static load capacity C0 [N]	22400.0
Note: static load capacity C0	Load on bearing (see general technical notes and information for bearings, "Project planning notes")
Dimension A1 (profiled rail systems) [mm]	47
Dimension A2 (profiled rail systems) [mm]	51
Dimension B (profiled rail systems) [mm]	22
Dimension D [mm]	38.45
Dimension d [mm]	15
Tolerance D [mm]	+0.03; -0.01
Dimension d2 [mm]	6.6
Dimension H [mm]	24.0
