5CFCRD.0128-03 | B&R Industrial Automation

Name: 5CFCRD.0128-03 | B&R Industrial Automation
Brand: B&R
SKU: 5CFCRD.0128-03
Price: 26.50 EUR
Availability: InStock

MPN: 5CFCRD.0128-03 · Brand: B&R

€26.50 excl. VAT & shipping

Request a Quote

3-month warranty

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	In stock — 6 available
Category	Memory Modules & Cards
Warranty	3-month

Shipping & availability

When can 5CFCRD.0128-03 be shipped?

5CFCRD.0128-03 is in stock and typically ships within 1 business day via UPS, DHL or FedEx, worldwide.

Can I pick up 5CFCRD.0128-03 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — alongside standard UPS, DHL and FedEx shipping, express (next-day) delivery is available at checkout for in-stock items like 5CFCRD.0128-03.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 5CFCRD.0128-03, subject to availability and destination.

CompactFlash 128 MB Western Digital (SLC)

Specifications

General information

Continuous reading – Typical	8 MB/s
Continuous writing – Typical	6 MB/s
Certifications – CE	Yes
Certifications – UKCA	Yes
Certifications – UL	cULus E115267; Industrial control equipment
Certifications – DNV	Temperature: A (0 to 45°C); Humidity: B (up to 100%); Vibration: A (0.7 g); EMC: B (bridge and open deck)
Capacity	128 MB
Data retention " data-placement="top" data-html="true" data-container="body" data-content="Per JEDEC (JESD47), EOL conditions are not permitted to be reached before 18 months. A higher average daily write workload reduces the expected service life and data retention of the data storage medium.">	10 years
Data reliability	<1 unrecoverable error per 10 14 bits read
Lifetime monitoring	Yes
MTBF	>4,000,000 hours (at 25°C)
Servicing	None
Supported operating modes	PIO mode 0-4, multiword DMA mode 0-2

Endurance " data-placement="top" data-html="true" data-container="body" data-content="Per JEDEC (JESD47), EOL conditions are not permitted to be reached before 18 months. A higher average daily write workload reduces the expected service life and data retention of the data storage medium.">

Erase/Write cycles – Typical	>2,000,000
SLC flash memory	Yes
Wear leveling	Static
Error-correcting code (ECC)	Yes
S.M.A.R.T. support	No

Support

Operating systems – Windows 7 32-bit	No
Operating systems – Windows 7 64-bit	No
Operating systems – Windows Embedded Standard 7 32-bit	No
Operating systems – Windows Embedded Standard 7 64-bit	No
Operating systems – Windows XP Professional	No
Operating systems – Windows XP Embedded	No
Operating systems – Windows Embedded Standard 2009	No
Operating systems – Windows CE 6.0	Yes
Operating systems – Windows CE 5.0	Yes
Software – PVI Transfer	≥V2.57 (part of PVI Development Setup ≥ V2.5.3.3005)
Software – B&R Embedded OS Installer	≥V2.21
Hardware	MP100/200, PP100/200, PP300/400, PP500, PPC300, PPC700, PPC725, PPC800, Provit 2000, Provit 5000, APC620, APC680, APC810, APC820

Ambient conditions

Temperature – Operation	0 to 70°C
Temperature – Storage	-50 to 100°C
Temperature – Transport	-50 to 100°C
Relative humidity – Operation	8 to 95%, non-condensing
Relative humidity – Storage	8 to 95%, non-condensing
Relative humidity – Transport	8 to 95%, non-condensing
Vibration – Operation	Max. 16.3 g (159 m/s² 0-peak)
Vibration – Storage	Max. 30 g (294 m/s² 0-peak)
Vibration – Transport	Max. 30 g (294 m/s² 0-peak)
Shock – Operation	Max. 1000 g (9810 m/s² 0-peak)
Shock – Storage	Max. 3000 g (29430 m/s² 0-peak)
Shock – Transport	Max. 3000 g (29430 m/s² 0-peak)
Elevation – Operation	Max. 24,383 m
