4-Channel Analog Input Resistance Sensor/Thermoc. + 4P IOL-A; Profinet; DC 24 V / 2.0 A; 8xM12 connection; WideLine
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | I/O Systems |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 765-2102/100-000 be shipped?
765-2102/100-000 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 765-2102/100-000 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 765-2102/100-000 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 765-2102/100-000, subject to availability and destination.
<p>Application area:</p><p>Decentralized processing of analog, digital and IO-Link signals</p><p> </p><p>This device records analog resistance temperature devices (RTD), thermalcouples (TC), Potentiometer setting and mV sensors. The Device also records and controls IO-Link-capable digital field devices, e.g., sensors, actuators and hubs, that are received or controlled by a higher-level controller. </p><p>In addition, the device offers four IO-Link ports or 8 digital inputs/outputs designed as Class A Master.</p><p> </p><p>Analog inputs:</p><p>The device has four electrically isolated analog channels for differential analog signal acquisition from the field areas and support RTD acquisition in 2-wire, 3-wire and 4-wire technique.</p><p>The cold junction compensation of the respective channel is externally connected to WAGO compensating connector (Item No. 756-9207/050-000)</p><p> </p><p>IO-Link:</p><p>The device has several IO-Link communication interfaces for collaboration with IO-Link devices.</p><p>The IO-Link interface allows direct access to the process and diagnostic data and allows you to set the parameters of the connected devices during operation.</p><p>The IODD can also be downloaded via IODDfinder <a href="https://ioddfinder.io-link.com">https://ioddfinder.io-link.com</a>.</p>
Specifications
Technical data - Fieldbus
| Communications | PROFINET, PROFINET IO device; 2-port switch, LLDP, MRP, SNMP |
| Connection technology: communication/fieldbus | 2 x D-coded M12; 4-pole |
| Interface standard | 10BASE-T/100BASE-TX; potential-free |
| Autonegotiation; autocrossover | Yes |
| PROFINET IO features | PROFINET IO device; 2-port switch, LLDP, MRP, SNMP |
Technical data - Device functions
| Parameter | Input filter, Output current, Temperature |
| Diagnostics | Undervoltage; overcurrent; overload; overtemperature |
| Device functions | Bluetooth®, OPC UA server |
| Visualization | Android/iOS app, Web server |
Technical data - Analog inputs
| Number of analog inputs | 4 |
| Signal type | Resistive temperature device, Resistors, Potentiometer positions |
| Signal characteristics | Differential |
| Measurement range | RTDs: Pt100, Pt200, Pt500, Pt1000, Ni100, Ni120, Ni200, Ni500, Ni1000, Ni1000-TK5000; Resistors: 250 Ω, 500 Ω, 1 kΩ, 2 kΩ, 4 kΩ, PTC; Potentiometer setting: 0 … 100 %; Thermocouples: Type B; Type C; Type E; Type J; Type K; Type N; Type R, S; Type T; mV sensor: ±30 mV; ±60 mV; ±120 mV; ±250 mV; ±500 mV; ±1,000 mV; ±2,000 mV |
| Sensor connection | RTD/R: 2-wire; 3-wire; 4-wire; TC/U 2-wire |
| Data width | 4 x 16-bit data; 4 x 8-bit status (optional) |
| Conversion time | ≥10 ms/2 wires (per channel)*; ≥20 ms/3 wires, 4 wires (per channel)*; *for RTD/R; TC/U conversion time depends on module setting |
| Conversion method | Sigma Delta |
| Resolution (over entire range) | 16 Bit (15 bits + sign); Resolution in process image: 0.1 K of full scale value; 0.01 K of full scale value (restricted to -50 °C ...+150 °C) |
| Measurement error (25 °C) | In delivery state: all types except J: ±0.1 % of full scale value; Type J: |
| Temperature coefficient | ≤±0.003 %/K of full scale value for voltage measurement and resistance measurement; ≤±0.01 %/K of full scale value for thermocouples (value achieved during calibration in operating environment -25 = TA = 70 °C) |
| Measuring current (typ.) | 0.1 mA (RTD) |
| Cold junction compensation | externally (Item No. 756-9207/0050-0000) |
| Connection requirement (permissible cable type) | Shielded |
| Connection requirement (permissible cable length) | 30 m |
| Advanced diagnostics | Measurement range underrange/overrange; User Measurement range underrange/overrange; Measurement range underflow/overflow |
| Isolation | Functional insulation: 2000 VDC system/channel; 800 VDC channel/channel |
Technical data - IO-Link master
| IO-Link master classification | Class A; V1.1 specification |
| Port-Modus | IO-Link: autoconfig, manual, tool-based, DI, DO |
| Cycle time | 400 μs (min.) |
| Operating mode | IO-Link master, DI or DO (adjustable for pin 4 per port); DI or DO (adjustable for pin 2 per port) |
Technical data - Supply (module)
| Connection technology: supply | 2 x L-coded M12; 5-pole |
| Supply voltage | 24 VDC (18 … 31.2 V); 1L; (2L looped through) |
| Current consumption (max.) | 16000 mA |
| Current consumption (note) | per supply line; overload- and short-circuit-protected; 12 A at 70 °C; Analog Port Current comsuption (max): 0.1 A |
| Reverse voltage protection | Yes |
Technical data - IO-Link ports
| Number of digital inputs | 8 |
| Number of digital outputs | 8 |
| Signal type (voltage) | 24 VDC |
| Input characteristic | high-side switching |
| Input filter | 0.2 … 20 ms |
| Input characteristic | Type 3, per IEC 61131-2 |
| Output current (per channel) | 2 A (typ.) for DO |
| Supply current per port | 1L: 1 A for IO-Link; 4 A (max.) for DIO |
Technical data - Connection data
| Connection technology: I/O | 4 x A-coded M12; 5-pole (IO-Link port); 4 x A-coded M12; 5-pole (Analog input) |
Physical data
| Width | 60 mm / 2.362 inches |
| Height | 30 mm / 1.181 inches |
| Depth | 210 mm / 8.268 inches |
Material data
| Weight | 574 g |
| Conformity marking | CE |
Environmental requirements
| Ambient temperature (operation) | -25 … +70 °C |
| Ambient temperature (storage) | -40 … +80 °C |
| Protection type | IP67 |
| Protection class | III |
| Pollution degree | 3 (EN 60664-1) |
| Operating altitude | 0 … 2000 m / 0 … 6562 ft |
| Relative humidity (without condensation) | 95 % |
| Vibration resistance | 5g per IEC 60068-2-6 |
| Shock resistance | Short-term: 50g/11 ms/half-sine per IEC 60068-2-27; Long-term: 30g/6 ms/half-sine per IEC 60068-2-29 |
| EMC immunity to interference | per EN 61000-6-2 |
| EMC emission of interference | per EN 61000-6-4 |
Commercial data
| PU (SPU) | 1 pcs |
| Packaging type | Box |
| Country of origin | DE |
| GTIN | 4066966779585 |
| Customs tariff number | 85371098990 |
Product Classification
| UNSPSC | 32151705 |
| ECCN | NO US CLASSIFICATION |
Environmental Product Compliance
| RoHS Compliance Status | Compliant,No Exemption |
