Fitted pluggable connector; 5-pole, shielded; M12 plug, straight; IDC technology
MPN: 756-9701/050-000 · Brand: Wago
Price on request
Request a Quote
12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
Quick facts
| Availability | Confirmed on request |
| Category | Interface Modules and System Wiring |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 756-9701/050-000 be shipped?
756-9701/050-000 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 756-9701/050-000 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 756-9701/050-000 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 756-9701/050-000, subject to availability and destination.
Fitted pluggable connector; 5-pole, shielded; M12 plug, straight; IDC technology 756-9701/050-000
Specifications
Technical data
| Connection type | M12 plug |
| Pole number | 5 |
| Cable connection direction to mating direction | 0 ° |
| Connector interface coding (cable/adapter) 1 1 | L-coded |
| Rated impulse withstand voltage | 1.5 kV |
| Contact resistance | 10 mΩ |
| Insulation resistance | >108 Ω |
Connection data
| Connection type | Pin penetration technology |
| Solid conductor | 0.75 … 1.5 mm² / 18 … 16 AWG |
Mechanical data
| Housing material | Zinc die casting |
| Tightening torque | 0.6 Nm |
| Weight | 84.7 g |
Environmental requirements
| Ambient temperature (operation) | -40 … +85 °C |
| Protection type | IP65 |
| Note on protection type | IP67 when mated; per IEC 60529 |
| Pollution degree | 3 |
Commercial data
| PU (SPU) | 1 pcs |
| Packaging type | bag |
| Country of origin | RO |
| GTIN | 4066966072228 |
| Customs tariff number | 85366990990 |
Product Classification
| UNSPSC | 39121413 |
| ETIM 9.0 | EC002584 |
| ETIM 10.0 | EC002584 |
| ECCN | NO US CLASSIFICATION |
Environmental Product Compliance
| RoHS Compliance Status | Compliant,No Exemption |
