Available on request
Fitted pluggable connector; 8-pole; M12 socket, right angle; Screw
MPN: 756-9214/090-000 · Brand: Wago
Price on request
Request a Quote
12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
Quick facts
| Availability | Confirmed on request |
| Category | Interface Modules and System Wiring |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 756-9214/090-000 be shipped?
756-9214/090-000 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 756-9214/090-000 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 756-9214/090-000 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 756-9214/090-000, subject to availability and destination.
Fitted pluggable connector; 8-pole; M12 socket, right angle; Screw 756-9214/090-000
Specifications
Technical data
| Connection type | M12 socket |
| Pole number | 8 |
| Connection point (shielded) | yes |
| Cable connection direction to mating direction | 90 ° |
| Connector interface coding (cable/adapter) 1 1 | A-coded |
Connection data
| Connection type | Screw clamp technology |
| Solid conductor | 0.14 … 0.75 mm² |
Mechanical data
| Connectable sheathed cable diameter | 6 … 8 mm |
| Weight | 68.6 g |
Environmental requirements
| Protection type | IP67 |
Commercial data
| PU (SPU) | 1 pcs |
| Packaging type | box |
| Country of origin | HU |
| GTIN | 4050821643067 |
| Customs tariff number | 85366990990 |
Product Classification
| UNSPSC | 39121413 |
| eCl@ss 10.0 | 27-24-26-92 |
| eCl@ss 9.0 | 27-24-26-92 |
| ETIM 9.0 | EC002584 |
| ETIM 10.0 | EC002584 |
| ECCN | NO US CLASSIFICATION |
Environmental Product Compliance
| RoHS Compliance Status | Compliant,With Exemption |
| RoHS Exemption | 6(c) |
| SCIP notification number (Austria) | 8f633e1d-e202-44cf-9b66-8c419f2be103 |
| SCIP notification number (Belgium) | 10562b90-daaa-4e74-b7dc-b2ac38abcc06 |
| SCIP notification number (Bulgaria) | c38ee00e-2c47-4246-8b06-a8b242fa7211 |
| SCIP notification number (Czech Republic) | 7dc10d8f-d6a2-42fa-b842-d760527bd043 |
| SCIP notification number (Denmark) | bf686c48-3d2c-4318-952a-e564ee95a606 |
| SCIP notification number (Finland) | deb6fb35-19ab-4a65-b54d-78593f5e5685 |
| SCIP notification number (France) | d29ccc71-c197-40ac-a40d-5794d2433e02 |
| SCIP notification number (Germany) | 961be597-c46f-40b6-b29d-fedb176d3f96 |
| SCIP notification number (Hungary) | bfad9d4e-08b6-4852-9bfc-44e7b66cb841 |
| SCIP notification number (Italy) | 409834e2-dcdd-4b9d-aabc-55a3c6bd59e6 |
| SCIP notification number (Netherlands) | 7462a7b1-c041-4972-8431-f6071c94fa04 |
| SCIP notification number (Poland) | aaa89fb9-8ab6-4319-ae32-62cb7167cb06 |
| SCIP notification number (Romania) | 8604ae27-d717-4ea7-9099-4c328869e680 |
| SCIP notification number (Sweden) | 7f5608db-021e-411e-80ea-f5977a8d9f19 |
