Siemens 1PH8165-1DG00-0LA1-Z K24+V24 – SIMOTICS M compact asynchronous motor 2300 r/min, 44 kW

Name: Siemens 1PH8165-1DG00-0LA1-Z K24+V24 – SIMOTICS M compact asynchronous motor 2300 r/min, 44 kW
Brand: Siemens
SKU: 1PH8165-1DG00-0LA1-Z K24+V24

MPN: 1PH8165-1DG00-0LA1-Z K24+V24 · Brand: Siemens

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Servo & Motion Control
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	230 kg

Shipping & availability

When can 1PH8165-1DG00-0LA1-Z K24+V24 be shipped?

1PH8165-1DG00-0LA1-Z K24+V24 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1PH8165-1DG00-0LA1-Z K24+V24 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1PH8165-1DG00-0LA1-Z K24+V24 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1PH8165-1DG00-0LA1-Z K24+V24, subject to availability and destination.

SIMOTICS M compact asynchronous motor 2300 r/min, 44 kW, 183 Nm, 85 A, 394 V forced ventilation; direction of air flow DE--> NDE; IP55 degree of protection with commutation position (encoder IC22DQ) with DRIVE-CLiQ interface, type of construction IM B3 plain shaft without feather key; bearing version: performance vibration class: special/B; shaft and flange accuracy: special terminal box (top) cable entry on the right signal port DE K24: primer (pale green) V24: special shaft extension d40x70mm customer-specific motor SMR-31-2016
