Siemens 1PH8133-1EB12-0BB2-Z Q80
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Servo & Motion Control |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 106 kg |
Shipping & availability
When can 1PH8133-1EB12-0BB2-Z Q80 be shipped?
1PH8133-1EB12-0BB2-Z Q80 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 1PH8133-1EB12-0BB2-Z Q80 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 1PH8133-1EB12-0BB2-Z Q80 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1PH8133-1EB12-0BB2-Z Q80, subject to availability and destination.
SIMOTICS M compact asynchronous motor 400 r/min, 5.2 kW 124 Nm, 15.5 A, 309 V 500 r/min, 6.5 kW, 124 Nm, 15.5 A, 363 V 600 r/min, 7.8 kW, 124 Nm, 15.5 A, 421 V forced ventilation; direction of air flow NDE--> DE; IP55 degree of protection absolute encoder EnDat 2048 S/R (encoder AM2048S/R) type of construction IM B5 (IMV 1, IM V3) plain shaft without feather key; bearing version: standard vibration class: R/A; shaft and flange accuracy: R terminal box (top); cable entry left; signal port DE Q80: increased bearing preloading
